CO2 Welding Wire, Mig Welding Wire ER70S-6
Description
Mig welding wire s is a coppered low alloy steel wire with all position welding.The wire has a very good
welding performance and the weld metal shows lower temperature impact toughness. It is mainly for welding structures made by shipping steel and low alloy steel, such as ships , containers, as well as vehicles,engineering
and construction machineries, bridges etc.
Advantages
This ER70s-6 CO2 welding wire has excellent mechanical performance such as depositing speed and high efficiency, stable arc, little splash, good welding seam. This series of welding wires are suitable for the low
carbon steel and low alloy structure, vehicle, bridge, container, construction machinery, boilers and construction etc.have depositing speed and high efficiency, stable arc, little splash, good welding seam.
*Avaliable mig wire size : 0.8mm, 0.9mm, 1.0mm, 1.2mm, 1.6mm
*Packing: 5kg, 15kg, 20kg/roll
Application
Suitable for welding low carbon steel and some low alloyed steel with grade 500MPA and grade D&E steel
for marine use. Such as vessels, vehicles, bridges, construction machinery, pressure vessels, construction
and so on.
Main Characteristics
All position welding, vertical-down ward welding ; Little splash, stable eletric arc and little weld fume; Good removability of slag, beautiful welding seam and can obtain high welding speed
in fillet welding.
Protection gas: 100% CO2
18Equivalent Standard: AWS A 5
| Size | Weight/roll | Packing size | Packing |
| 0.8mm | 15kg | 180mm*180mm*110mm | 15kg/carton |
| 1.0mm | 20kg | 180mm*180mm*110mm | 20kg/carton |
| 1.2mm | 20kg | 180mm*180mm*110mm | 20kg/carton |
| 1.6mm | 20kg | 180mm*180mm*110mm | 20kg/carton |
| 2.0mm | 20kg | 180mm*180mm*110mm | 20kg/carton |
- Diameter: 0.8mm, 0.9mm, 1.0mm, 1.2mm, 1.6mm
- Chemical composition: C 0.06-0.15, Mn 1.40-1.85, Si 0.80-1.15, P < =0.025, S < =0.035, Cu < =0.35,
Ni < =0.30, Cr < =0.20
- Weight of spool: 5kg, 15kg and 20kg.
- Packing of welding wire:
| Wire Size | Spool Size | Weight |
|
0.8mm 1.0mm 1.2mm 1.6mm |
D100mm D200mm D270mm D300mm K300mm |
1kg, 5kg, 15kg, 20kg |
|
chemical composition of welding wire(%) |
C | Mn | Si | P | S | Cr | Ni | Cu |
| 0.06~0.15 | 1.40~1.85 | 0.80~1.15 | ≤ 0.025 | ≤ 0.035 | - | - | ≤ 0.50 | |
|
Mechanical Properties or Deposited Metal |
Yield strengthσ 0.2(Mpa) | Tensile strengthσ b(Mpa) |
Elongationδ 5(%) |
AKV impact(J) | ||||
| ≥ 420 | ≥ 500 | ≥ 22 | ≥ 27(-29) | |||||
|
Wire Size (mm) |
φ 0.8 | φ 1.0 | φ 1.2 | φ 1.6 | Welding position |
