Home > Products > Frame Scaffolding > 1219*1700 mm painted Scaffolding Mason Frame
1219*1700 mm painted Scaffolding Mason Frame
- 100000 Set / Sets per Month
- QINGDAO
- T/T
- High Quality Construction Metal Scaffolding Frame
- Frame system Scaffolding Rental used in constructions
- Door type Galvanized arch Frame Scaffolding
- 1930*1219 mm h scaffolding Frame for Sale
- Construction scaffolding system/ arch frame scaffolding/Snap Frame
- ALL SizeSwivel Industrial Heavy Duty Caster Wheel
Product Details
Place of Origin: | Shandong, China | Brand Name: | QUEEN | Model Number: | 1200 |
Packaging Details
by steel pallet
Product Description
Specifications
Mason Frame1)Material:Q235,Q195
2)Size:1219x1700x1800mm
3)pipe:42*2.2mm/48*2.5mm
4)Aviliable height for use : 20M
Box frame scaffolding/Walk frame scaffolding/ Mason Frame
Shoring frames are used to support the imposed loads. Cross braces are used to connect the frames together, forming a rigid tower to provide maximum stability and strength in virtually any shoring application.
1.Raw materil Q235
2.Tube:42x2.0mm,42x2.3mm,40x1.8mm,42x2.5mm,48*2.5mm.60*2.5mm
3.Size 914mmx1700mm,956mmx1700mm,1219mmx1700mm,914mm x 914mm, 914mm x 1,524mm, 914mm x 1,829mm, 1,524mm x
1,524mm, 1,524mm x 1,829mm.
4.Anti-rust cotaing: Powder coated,galvanized,hot dipped galvanized
5.6"or 8”Caster and hollow or solid screw jack are for your choice
6.Stacked up to 20M maximum
7.OEM is offer
Specifications of the Mason Frame
STD/ Ledger(P.G.)mm | Size (mm) | KG | STD/ Ledger(H.D.G.)mm | Size (mm) | kg |
Φ42*2.2/Φ42*2.0 | 1930*1219 | 15.05 | Φ42*2.2/Φ42*2 | 1930*1219 | 15.05 |
Φ42*2.0/Φ42*2.0 | 1930*1219 | 14.33 | Φ42*2/Φ42*2 | 1930*1219 | 14.33 |
Φ42*2.1/Φ42*2 | 1930*1219 | 14.43 | Φ42*2.1/Φ42*2 | 1930*1219 | 14.43 |
Φ42*2.2/Φ42*2 | 1700*1219 | 13.51 | Φ42*2.2/Φ42*2 | 1700*1219 | 13.51 |
Φ42*2/Φ42*2 | 1700*1219 | 12.88 | Φ42*2/Φ42*2 | 1700*1219 | 12.88 |
Φ42*2.1/Φ42*2 | 1700*1219 | 13.20 | Φ42*2.1/Φ42*2 | 1700*1219 | 13.20 |
Φ42*2.2/Φ42*2 | 1524*1219 | 12.21 | Φ42*2.2/Φ42*2 | 1524*1219 | 12.21 |
Φ42*2/Φ42*2 | 1524*1219 | 11.64 | Φ42*2/Φ42*2 | 1524*1219 | 11.64 |
Φ42*2.1/Φ42*2 | 1524*1219 | 12.00 | Φ42*2.1/Φ42*2 | 1524*1219 | 12.00 |
Φ42*2.2/Φ42*2 | 914*1219 | 9.56 | Φ42*2.2/Φ42*2 | 914*1219 | 9.56 |
Φ42*2.2/Φ42*2 | 1930**914 | 14.19 | Φ42*2.2/Φ42*2 | 1930*914 | 14.19 |
Φ42*2/Φ42*2 | 1930**914 | 13.47 | Φ42*2/Φ42*2 | 1930*914 | 13.47 |
Φ42*2.2/Φ42*2 | 1700*914 | 12.65 | Φ42*2.2/Φ42*2 | 1700*914 | 12.65 |
Φ42*2/Φ42*2 | 1700*914 | 12.02 | Φ42*2/Φ42*2 | 1700*914 | 12.02 |
Φ42*2.2/Φ42*2 | 1524*914 | 11.60 | Φ42*2.2/Φ42*2 | 1524*914 | 11.60 |
Φ42*2/Φ42*2 | 1524*914 | 11.03 | Φ42*2/Φ42*2 | 1524*914 | 11.03 |
Specifications of frame scaffolding:
- 1. One set of frame scaffolding system consists of two H type frame scaffolding, two pairs of cross bar, four piece of joint pins, additional steel plank, jack base, caster wheels, etc.
- 2. Frame scaffolding system is widely use as movable platform, install the caster wheels at the bottom tube, for inside wall painting and decoration; also applicated in build constrution ourside working platform system; in some country, frame scaffolding is for inside suport system, which connect U jack on the top, for concere, slab support.
- 3. Frame scaffolding system is easy assembly and time saving, just need to connect two H frame by cross bar, and up together by joint pins.
- 4. Frame scaffolding can be surface treatment red oil painting or Hot dip galvanized to further resist rust, cracking and corrosion, has no pollution or harm to the evironment and people, which make sure of its low damage and longer life span.
- 5. Frame scaffolding can be packed by steel wiress or in bulk, which is easy to ship.
Application of Mason Frame :
1. Apply to a high work platform, such as building, hall, bridge, viaduct, tunnel, etc.
2. Apply to inside and outside scaffolding fence.
3. Using for movable work platform,such as electronic machinery,hull repairing and other decorating projects.
About us
We specialized in the filed of the hardware and scaffolding systems for10 years time and we dealing with many kinds of the Scaffolding .like Ringlock.Cuplock.Kwikstage scaffolding .frame systems. Shoring propsystems. hardware like handtools, Auto Tools. Building tools, such as the ratchet wrench.Pickaxe, Firmer chisel,shovel, pickaxe,various hammers,Triangle bricklayer,Scraper and so on. We want to emphasize that our goods get the reputation in the market due to the competitive price with the high quality. please do not hesitate to contact us meanwhile we will offer you the best with the quality you satisfied.
Company Profile
Since 2000, we has been specialized in manufacturing scaffoldings, kwik stage/ringlock/cuplock/frame scaffoldings, steel planks, couplers, accessories & formwork parts, and hardware, ratchet wrench tools, garden tools, sockets and accessories. We expand our products to hand tools, automotive tools, etc. We have more than 10 years of production and export experience. Each tool produced by Queen is in the best quality, with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of markets around the world.
We have a highly experienced producing team, which maintains top level of every stage of the producing progress. Each team of workers is led by supervisor who monitors day to day works. Automated welding and robot systems are widely used.
Today, we have customers in over 35 countries around the world. Our products are engineered for safety, strength and flexibility to meet international standards within this industry. It is important for structural engineers, scaffolding factories and formwork specialists. In terms of working processes, we have expertise in iron casting, steel forging and thread rolling. We have a complete quality control system, which guarantees the high quality of our products and makes sure all progress is made to schedule.
With all our technical knowledge and capacity, if you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationships with new clients in the near future.
