Model ACD Torque Spanner(Pointer-type)

Model ACD Torque Spanner(Pointer-type) photo-1
US$ 2 - 50 MOQ: 200 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
kbd
Model Number:
ACD5
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Jiangsu, China
Brand Name kbd
Model Number ACD5
Type Other
Material Alloy
Size 6.3*6.3mm

Specifications

1.High precision good stability
2.Suitable for torque moment measuing of fastening

Features

1.High precision good stability
2.Suitable for torque moment measuing of fastening
3.precision  ±3%

Speciticatios
Speciications
Range of Torque Moment
(N.m)
Dimensions of
Square Tenon
(mm)
Overview Dimensions
L×W×H(mm)
Scale value of
the scale
(N.m)
Weight
(kg)
ACD5
0-5
6.3×6.3
230×72×57
0.1
0.4
ACD10
2-10
6.3×6.3
253×72×75
0.2
0.5
ACD30
0-30
10×10
253×72×75
0.5
0.5
ACD100
0-100
12.5×12.5
310×72×60
2
0.8
ACD300
100-300
12.5×12.5
645×72×75
5
1.8
ACD750
150-750
20×20
1810×72×85
20
15.5
ACD1000
200-1000
20×20
1810×72×85
20
15.5
ACD2000
400-2000
25×25
1810×72×85
40
15.5
ACD4000
800-4000
38×38
1810×72×85
80
18

Operation Instruction

 Reset
  1,Rotate the casing of the dial plate and make the main pointer point to "zero"
  place.
  2,Fix corresponding sleeve on the square tenon and ring the fastening parts
  3,Bring pressure to bar o te handle slowly.
  4,Leave go of your hand after the pointer reaches the value o torque moment
  needed.
Repeat the former process when you euse it.
