Specifications
1. CE certificate2. Laminated paper, 500gsm MAX thickness and common paper
3.SGS certificated
A3+Business Name Card Cutting Machine,card cutting machine
A3+ Electric Business Card Cutting Machine
Way of cutting |
Longitudinal: rolled cutting by a roller; horizontal: cutting by a lateral long cutter |
Way of paper feeding |
Automatic paper feeding in double rubbing way |
Size of paper |
A3+(320×480mm); A3(297×420mm); SRA3(320*450mm), |
Thickness of paper |
0.20mm(180g/m²)---0.30mm(350g/m²) |
Paper nature |
Common paper, quality paper |
Cutting speed |
For namecards, about 100pcs/min |
Cutting size |
Longitudinal: 55 or 54mm and 89(or 85,90,95)mm
Horizontal: 40-250mm, adjustable
|
Volume of paper |
Maximum 12pcs (about 0.25mm thick) for namecards or total thickness 3mm |
Volume of namecard |
180g/m² 90×5pcs 250g/m² 70×5pcs |
Mechanical dimension |
570mm×540mm×280mm (L x W x H) |
Ambience of use |
-15∼+40 humidity 35%~70% |
Weight |
About 24Kg |
Power supply |
AC 90~260V, 50/60HZ, 0.5A |
Way of adjustment to cut different thickness of paper
When ex-factory, the thickness adjustment needle points to the middle, which means cutting 250g(about 0.25mm) thickness paper.
(A) If cutting paper that thicker than 250g(or 0.25mm):
1. Loosen the lock nut
2. Rotate the needle to "+" direction by cross-screwdriver. (It's 0.02mm thickness corresponding to each space)
3. Tighten the lock nut.
(B) If cutting paper that thinner than 250g(or 0.25mm):
1. Loosen the lock nut
2. Rotate the needle to "-" direction by cross-screwdriver. (It's 0.02mm thickness corresponding to each space)
3. Tighten the lock nut.
