Phenolic insulation sandwich panel:
Phenolic foam apanel is of high strength, taking the phenolic foam as the core material and with non-woven fabrics on both sides. It is non-combustible material, which has no smoke and innocuity while catching fire and the bending strength reaches over 1MPa and the thermal conductivity index reaches 0.020W/mK.It is widely used for the exterior wall systems in hotels, apartments, hospitals, office buildings and other deluxe high-rise buildings.
Good feature:
1.fireproof & insulation
2.its widely use in China many national project & foreign countries
3.we have 7 producting lines.
4.China biggest and eariest producting company for phenolic panel
5.we special make phenolic foam panel for exterior wall/phenolic air duct panel withboth sides of aluminum foil/phenolic air duct panel with color steel
Specifications:
1) Density: 50 - 60kg/m3
2) Thermal conductivity: 0.020W/mK
3) Compressing strength: 0.56MPa
4) Bending strength: 1.0Mpa
5) Combustibility property: non-combustible class "O"
6) Water absorption: 1.9%
7) Max. smoke density: 2%
8) Dimension change: 0.3%
9) Working temperature: 150°C
10) Dimensions: 600mm*900mm*20mm/30/40/50/60/70/80mm
