Phenolic foam insulation board/ Fireproof insulated exterior phenolic wall panel
Phenolic foam panel for outside wall or drywall
Huahai phenolic foam insulation board comapny is China bigest and eariest company for phenolic foam exterior wall panel&phenolic air dut panel.
phenolic foam insulation board,high strength, taking the phenolic foam as the core material and with non-woven fabrics on both sides. It is non-combustible material, which has no smoke and innocuity while catching fire and the bending strength reaches over 1MPa and the thermal conductivity index reaches 0.020W/mK.It is widely used for the exterior wall systems in hotels, apartments, hospitals, office buildings and other deluxe high-rise buildings.
Dimension of phenolic foam insulation board
Thickness: 20-120mm
Width: 600mm, 900mm, 1200mm
Length:1200mm, 2400mm, 3000mm or your option
performance index of phenolic foam insulation board
Bending strength | ≥1.1mpa |
Air leakage | 1.2% |
Density | 55-70 kg/m3 |
Dimension stability | ≤2% |
Thermal conductivity | 0.024-0.034W/m.k |
Fire Retardant Level | Anti-flamming level-B/non-combustible level A |
Water absorption | 3.7% |
Wind Press-resistant strength | 1500pa |
Heat Resistance | -150°C ··· +150°C |
Use of phenolic foam insulation board
phenolic foam insulation board is widly used as wall heat insulaiton and fireproof materials in tall buildings .because of it's good heat heati insulation rate and fireproof grade , it can work very well as external wall heat insulation materials .
Reputation of phenolic foam insulation board
1. low temperature foaming phenolic production,Patent number :ZL00 111275.9
2. by ISO9001:2000 quality certification,ISO14001:2004 environmental certification
3. passed British BS476,NEF Standard
4. passed United Arab Emirates’s National Standards
5. acquired "Chinese Green Environmental Protection Product" Title
6. our production line for this panel is named as “the first line in China”
7. National Fireproofing Materials Quality Supervision Center GB8624-19
