GC Specification
Inlet temperature: Max. 450℃
Pressure range: 0-100psi,±0.002psi
Pressure control mode: Electronic pressure control (EPC), support CV and CC
Split mode: Split/splitless, max. split ratio: 1000:1
Column oven working temperature: Room temperature+4℃～450℃
Heating rate: Up to 120℃/min
Temperature programming: 7 stages/ 8 platforms
Auto Sampler: Optional
MS specification
EI source ionization energy: 5 eV ---250 eV (Adjustable)
Mass range: 1.5- 1000amu
Resolution: Unit resolution (full width at half maximum)
Ion source temperature: 100—350℃
Filament emission current: 0-350 μA
GC-MS Interface Temperature: Max. 450℃
stability: ±0.10 amu/48 hrs
Sensitivity: Full scan, 1pg OFN at m/z 272 with S/N ≥30：1 (RMS)
Scan rate: Up to 10000 amu/s
Vacuum: Turbo molecular pump（67 L/s）
Detector: High-energy dynode electron multiplier
