HVAC Auminum Foil PU Foam Insulated Air Duct Panel

Specifications

HUAHAI  PU foam air duct panel

Dimension

2950/3950mm*1200mm*20mm

2950/3950mm*1200mm*25mm

2950/3950mm*1200mm*30mm

HVAC Pre-insulated  PU air duct panel

Type

Double sided aluminum foil  pu foam air duct panel

Double sided color steel pu foam air duct panel

Single sided GL pu foam air duct pane(the other side is alunimum foil)l

Single sided color steel  pu foam air duct panel (the other side is aluminum foil)

Performance index

Description

  1.Polyurethane foam pre-insulated air duct panel is used for air distribution in central air conditioning.

  2. The air ducts are made of pu foam sandwich panels, the panels composite rigid polyurethane insulation foam faced on both sides with a protective low vapour permeability 80micron aluminum foil .

  3.They are conpletely CFC and HCFC free, and are of highly thermal resistance.

  4.This panel is especially suit for using in air -conditioning and heating system installations.

Advantage

1. Excellent flame retardant properties, open flame only carbonation does not burs.

2.It's of good appearance , beautiful colors, light weight, high strength ,and easy installation.it's fireproof, water-proof and of good insulation property.By using this material, the user can save a lot of costs and time .

3.This air duct panel  is made of pu foam, it adopts new non-fluoride foaming technology, adds harmless auxiliary agents , uses special resin to change features, and through aluminium foil surface chemical treatment. The double sides are embossed aluminium foil ,and the inner layer is made of flame-retardant phenolic foam materials .

Main export countries and regions.

 Our products have been exported to more than thirty countries and regions such as USA , Australia, Korea, Cyprus, Iran, Singapore, India, Thailand, Myanmar, Norway and Canada, Trinidad and Tobago,Peru,Japan, Guam, Ghana,Laos, UAE, Indonesia, Taiwan, Panama, Philippines, etc.
