China Best Automatic Air Duct Production Line

Best air ducting production line/Air-conditioners ducts machine:

We special make the air duct panel and producting line more than 10 years.We are China biggest and eariest air duct panel manufacturer.

This producting line is a kind of specialized equipment for productinglaminated panels with middle layer of anti-combustion PU/PIR/Phenolic with aluminum foil as the top and bottom face layers or with color steel surface or PU/Phenolic foam.

Its main used place: ventilarion ducts for central air-conditioners./dry wall or exterior wall insulation panel.

Finished product information:

The thickness:20mm-100mm

Standard width:1200mm

Length:its can cut as your needs.

Main technical parameters

• Linear speed of production                 2~5 m/min
  Maximum embossing speed                 15 m/min to the maximum
  Agitating speed                           4500 r/min
  Reciprocating times of injection head per minute   <60
  Maximum temperature of hot-air circulating    70°C
  Laminating length of laminator              18 m
  Maximum clearance between conveyors     300 mm
  Total power of the line                     134KVA
  Weight                              ≈35 tons
• External dimensions of line                    37, 000×5,365×3,636 mm
• (Length×Width×Height)

The constituent parts of the production line are listed as follows:

One embossing machine unit including a decoiler, an embosser and a coiler

Two sheet-decoiling installations

One aluminum foil pre-heating mechanism

One low-pressure foaming machine

One mobile injector

One set of paper-posting installation

One conveyor laminator

One set of hot-air circulating installation

One edge-trimmer

One automatic-tracking cutter

One set of roller conveyor
