Double Side Planner & Up-Down Multiple Blade Rip Saw Series Machine With Working Width 300mm SHMJ430SBJ With Max Thickness130mm

Double Side Planner & Up-Down Multiple Blade Rip Saw Series Machine With Working Width 300mm SHMJ430SBJ With Max Thickness130mm photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Other
Use:
Woodworking
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Other
Use Woodworking
Style Vertical
Place of Origin Shandong, China
Brand Name SHOOT
Model Number SHMJ430SBJ
Voltage 380V
Power(W) 63.12kw
Dimension(L*W*H) 3500x1500x1600mm
Certification CE
Double Side Planner & Up-Down Multiple Blade Rip Saw Series Machine with Working Width 300mm
Feature
Professional solution, large quantities of wood materials such as wood material specifications carriage, double-sided planer multi chip sawing machine.
Saw shaft independent operation, frequency conversion transmission, according to the hardness of wood can choose reasonable conveying speed.
Hard chromium plating on the working table, smooth and wear resistance.
Up and down saw shaft independent electric lift, operation, quick, simple and convenient.
Up and down saws are responsible for 50% machining, high efficiency, energy saving and material saving.
Saw uranium setting water, jet cooling system, lifting the blade utilization.
ModelSHMJ430SBJ
Maximum working width300mm
Max Thickness130mm
Feeding speed5-25m/min
Knife shaft diameter125mm
Knife shaft speed6000r/min
Arbor move around10mm
Knife shaft motor power11kw
Under the knife shaft motor power7.5kw
Conveyor motor power3kw
Saw shaft diameter50mm
Saw shaft keyway16x5mm
Saw shaft speed4000r/min
Saw the largest diameter250mm
The vertical axis motor power saw18.5kw/22kw
Lift shaft power saw 0.37kw
Lift motor transport system0.75kw
Total motor power63.12kw
Dimensions3500x1500x1600mm



Double Side Planner & Up-Down Multiple Blade Rip Saw Series Machine with Working width 300mm SHMJ430SBJ with Max Thickness130mmDouble Side Planner & Up-Down Multiple Blade Rip Saw Series Machine with Working width 300mm SHMJ430SBJ with Max Thickness130mmDouble Side Planner & Up-Down Multiple Blade Rip Saw Series Machine with Working width 300mm SHMJ430SBJ with Max Thickness130mm
