CNC Band Saw SH-15.CNC With Wheel Dia.&Width 900X60mm and Minimum Cutting Radius 50mm and Saw Width 13mm
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
CNC
Place of Origin:
Shandong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CNC Band Saw SH-20.CNC With Wheel Dia.&Width 900X60mm and Minimum Cutting Radius 50mm and Saw Width 13mmNegotiableMOQ: 1 Piece -
CNC Band Saw SH-25.CNC With Wheel Dia.&Width 900X60mm and Minimum Cutting Radius 50mm and Saw Width 13mmNegotiableMOQ: 1 Piece
-
Multi-blade Wood Saw SH173B With Max. Working Dia. 240mm and Min. Working Dia. 80mmNegotiableMOQ: 1 Piece
-
Multi-blade Round Saw SH162 With Working Thickness 10-75mm and Max. Working Width 200mmNegotiableMOQ: 1 Piece
-
Woodworking Heavy Duty Band Saw Machine DJ970 With 7.5kw Motor and Auto Feed and High SpeedNegotiableMOQ: 1 Piece
Condition
New
CNC or Not
CNC
Place of Origin
Shandong, China
Brand Name
SHOOT
Model Number
SH-15.CNC
Certification
CE
| CNC Band Saw | |
| Model | SH-15.CNC |
| Wheel Dia.&Width | 900×60mm |
| Minimum Cutting Ladius | 50mm |
| Saw Width | 13mm |
| Saw Length | 5880mm |
| Saw Tilting | -90°~+90° |
| Sawblade Speed | 450-550rpm.50-60Hz |
| Cutting Capacity | 1500×900×150mm |
| Sawblade Drive Motor | 7.5KW |
| X Spindle | 2.0kw |
| Y Spindle | 1.0kw |
| Z Spindle | 0.75kwx2 |
| Control System | / |
| Working Capacity | 1-20m/min |
| Max Speed | 35m/min |
| Arc chair foot: |
| Board material size 920mm(long)x1150mm(wide). |
| Direct call design drawings or measurement of |
| workpiece material, template. |
| Figure 1 |
| Artificial feeding: |
| Real size: 43mm, due to the artificial feeding |
| precision is not enough, so to put allowance |
| 4mm, plus the saw kerf(i.e. saw blade thickness |
| 1-1.5mm), the actual material width 48.5mm, so |
| artificial discharging quantity:23-24. |
| CNC band discharge: |
| Because CNC bandsaw cutting high size precision, |
| therefore, discharge allowances generally only 2mm |
| can be, so the legend"1" to the use of CNC band |
| material, its actual material needs only 46.5mm, so |
| the same width (1150mm) sheet a: 24-25. This |
| saves expensive wood, and because of high |
| precision, sawing, the subsequent process more |
| convenient, easy; but also reduced the labor |
| intensity, reduce the tool wear, virtually more save |
| time. |
| Automatic generation of machining program. |
| First of all, the CAD file into DXF file format, |
| and then from the NC system interface directly |
| to open this file automatically generated. This |
| machine is considered in the design of the |
| utility, thus only needs to set the thickness |
| of the saw blade, processing speed and |
| other parameters can automatically generate |
| the required processing code. As the legend |
| "1" program to store codefor JL001. |
| In order to safety, material saving, the calling |
| program in the special simulation software |
| simulation processing. |
| Production program code stored once formed, |
| this procedure can be permanent call, after doing |
| the same products do not need to layout |
| progranning; as do the legend "1" in the product, |
| simply call the JL001 can; if manual typesetting |
| must do a first row, so it is a whole province a |
| procedure! |
