Home > Products > wood cutting panel saw > COMPUTER PANEL SAW SH330B with Max. cutting length 3280mm and Max. cutting thickness 90mm
COMPUTER PANEL SAW SH330B with Max. cutting length 3280mm and Max. cutting thickness 90mm
Negotiable
/ Piece
1 Piece(Min.Order)
- 200 Piece / Pieces per Month
- Qingdao Port
- T/T
You May Like
-
COMPUTER PANEL SAW SH1333B with Max. cutting length 3280mm and Max. cutting thickness 90mm
-
COMPUTER PANEL SAW SH1333 with Max. cutting length 3280mm and Max. cutting thickness 76mm
-
COMPUTER PANEL SAW SH330 with Max. cutting length 3280mm and Max. cutting thickness 76mm
-
Heavy Duty Planer and Thicknesser and Mortiser Machine SH424S with Max. planing width 410mm and Planing thickness 6~210mm
-
Woodworking Planer & Thicknesser Machine SH424 with 2000mm length planer table and 400mm width planer and 3kw motor
-
Combined Surface Planer-Thicknesser SH410D with Maximum planing width 410mm and Length of the tables 2220mm
Product Details
| Place of Origin | Shandong, China | |||
| Brand Name | SHOOT | Model Number | SH330B |
Product Description
| COMPUTER PANEL SAW | |
| MODEL | SH330B |
| Max. cutting length | 3280mm |
| Max. cutting thickness | 90mm |
| Diameter of main saw blade | 400mm |
| Diameter of main saw spindle | 60mm |
| Rotation speed of main saw blade | 4800rpm |
| Diameter of scoring saw blade | 180mm |
| Diameter of scoring saw spindle | 30mm |
| Rotation speed of scoring saw blade | 6500rpm |
| Forward speed of saw carriage(stepless) | 9-37m/min |
| Backward speed of saw carriage | 67m/min |
| Drive motor of main saw blade | 15kw |
| Drive motor of saw carriage | 1.5kw |
| Automatic feeding motor | 1.5kw(AC Servomotor) |
| Total power consumption | 20.2kw |
| Automatic feeding speed | 50m/min |
| Pnenmatic pressure | 5-7kg/cm2 |
| Table height from floor | 960mm |
| Net weight | 5500kg |
| Overall dimensions | 5830x6630x1750mm |
Option
| HYDRAULIC LIFT TABLE(OPTION) | |
| MODEL | MF7113 |
| Working table size | 2500x1300mm |
| Max. raising weight | 3000kg |
| Min. height of working table | 480mm |
| Max. raising height | 1900mm |
| Pump power | 1.5kw |
| Dia of oil cylinder | 100mm |
| Net weight | 1300kg |
| Overall dimensions | 2500x1300x420mm |
