SCM Series Centrifugal Pump

Specifications

Centrifugal pump

SCM series are single stage centrifugal pumps suitable for both domestic and industrial
applications to convey clean liquids and non-aggressive chemical fluids.

Working conditions:
1) Max. temperature of fluid up to: 80°C
2) Max. ambient temperature up to: 40°C
3) Max. pressure: 10 Bar

Structural characteristics:
1) Pump casing: cast iron
2) Impeller: brass
3) Motor housing: aluminum
4) Mechanical seal: stainless steel (graphite to ceramic)
5) Shaft: 45# steel or stainless steel
6) Bearing: SKF/NTN/NSK/China
7) Insulation class: B and F
8) Protection class: IP44 and IP54

Packing:
CARTON
