600W JET water pump

FOB Price

Negotiable / Piece

200 Pieces(Min. Order)

Port FOB FUZHOU CHINA
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Fujian, China	Brand Name	Huifeng
Model Number	JET	Theory	Jet Pump
Structure	Single-stage Pump	Usage	Water
Power	Electric	Standard or Nonstandard	Standard
Fuel	Other	Pressure	Other

Product Description

Specifications

600W JET water pump
Pump casing:Cast Iron
Impeller:ABS/Brass/Noryl
Diffuser:Noryl/PPO/ABS/Cast iron

600W JET water pump

1 .Working conditions:

Max temperature of fluid up to: 50°C

Max ambient temperature up to: 40°C

Max Pressure: 8bar

2. Structural characteristics:

Pump casing: Cast Iron

Impeller: ABS/Brass/Noryl

Diffuser: Noryl/PPO/ABS/Cast iron

Motor Housing: Aluminum

Pump-motor adaptor: Aluminum/Cast iron

Mechanical seal: Stainless steel(graphite to ceramic)

Shaft: 45# steel or stainless steel

Bearing: SKF/NTN/NSK/China

Insulation class: B and F

Protection class: IP44 and IP54

3. Technical data (220V,50HZ)

Model	Power		Q.MAX (L/min)	H.MAX (m)	S.Head (m)	Speed (r.p.m)	Pipe Dia (Inch)	N.W (kg)	Packing size (mm)
	W	HP
JET-60S	460	0.6	45	35	9	2850	1″* 1″	12.8	375188200
JET-80S	600	0.8	50	40				13.5
JET-100S	750	1	50	45				14.2

Model	Power		Q.MAX (L/min)	H.MAX (m)	S.Head (m)	Speed (r.p.m)	Pipe Dia (Inch)	N.W (kg)	Packing size (mm)
	W	HP
JET-60L	460	0.6	55	35	9	2850	1″* 1″	15.3	435188200
JET-80L	600	0.8	60	40				16.0
JET-100L	750	1	60	45				16.7

110V,115V,127V,230V,240V,110/220V,50HZ/60HZ,380V 50HZ three-phase etc.Models are acceptable if request.
