IE3 7.5kW IMB3 Three Phase Electric Motor

 IE3 7.5kW IMB3 Three Phase Electric Motor

TECHNICAL CHARACTERISTICS

• Rated outputs and frame sizes in accordance with IEC60034 standards
• Duty type S1(continuous duty)with sufficient thermal margin to withstand short overload
• Enclosure protection IP55
• Insulation class F, temperature rise class B
• Maximum ambient 40°C
• Altitude≤1000m a.s.l.

GENERAL SPECIFICATIONS

• Terminal box rotates 4x90°
• Removable feet, multi mount-terminal box left or right hand side
• Enclosed shaft key

CONSTRUCTION MATERIALS

• Frame – Aluminium
• End shields- Aluminium/Cast iron
• Fan cowl- steel
• Fan-Plastic
• Shaft- Medium carbon steel(stainless available on request)
• Terminal box – Aluminium

Technical Information.

IM Information
