Home > Electrical & Electronics > Electric Motor > AC Motor > Single Phase Dual Capacitor 1.5hp B5 Electric Motor
Single Phase Dual Capacitor 1.5hp B5 Electric Motor
US$ 1 - 2,000
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Brand Name:
HUIHENG or OEM
Model Number:
ML
Type:
Induction Motor
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
400/600V 18.5kW AC Three Phase IE3 Electric MotorNegotiableMOQ: 60 Pieces -
IE3 B3 18.5kW Three Phase IE3 MotorNegotiableMOQ: 100 Pieces
-
315KW IE3 Electric Motor With CEUS$ 50 - 6,500MOQ: 50 Pieces
-
IMB14 Single Phase MotorUS$ 1 - 2,000MOQ: 100 Pieces
-
IE2 IE3 Three Phase Electric MotorNegotiableMOQ: 100 Pieces
Brand Name
HUIHENG or OEM
Model Number
ML
Type
Induction Motor
Frequency
50/60Hz
Output Power
1.1kW(1.5HP)
Protect Feature
Other, Totally Enclosed, Enclosed
Certification
CCC, CE, ROHS
AC Voltage
Other, 230V
Place of Origin
Fujian, China
Efficiency
Other
Specifications
single phase dual capacitor 1.5hp B5 electric motor1.24 years manufacturing experience
2.ISO9001,TUV,CE;
3.18 months
single phase dual capacitor 1.5hp B5 electric motor
MOTOR FEATURES
1) utilise IP55 enclosures, IP54 on request
2) Multiple feet locations
3) Aluminum frame. end shields and base
4) High strength cable gland
5) Shaft key and protector supplied
6) Superior paint finish
7) Motors made to heavy duty service factors
8) Utilise Vacuum impregnated Class B insulation
9) Class F insulation on request
10) High performance and efficiency
CUSTOMER BENEFITS
1) Water dust and vermin resistant
2) Quiet operation
3) Electricity saving
4) Easy installation (bolt on feet or brackets as required)
5) Corrosion resistant
6) Dependable
7) Superior life
8) Reliable in contury, city or factory environments
WHY CHOOSE US
WHAT WE DO AT HUIFENG
- Stamping of lamination
- Rotor die-casting
- Winding and inserting – both manual and semi-automatically
- Vacuum varnishing
- Machining shaft, housing, end shields, etc…
- Rotor balancing
- Painting – both wet paint and powder coating
- Motor assembly
- Packing
- Inspecting spare parts every processing
- 100% test after each process and final test before packing.
WHAT HUIFENG CAN DO FOR CUSTOMERS
- Huifeng supplies standard products to customers.
- Huifeng supplies standard products under customers’ brands and packaging, etc
- Huifeng R&D department develops any new products together with the customers.
OUR FACTORY
- Established:1989
- Total land: 26,800 square meters; 16,000 square meter workshop, laboratory and office.
- Employees: 350
- Engineers: 10 work in R&D and 17 in factory production
- Estimated turnover: 2008: Eur.14,500,000; 2009: Eur.12,100,000; 2010: Eur.13,200,000 about 60% to Europe and 30% to Australia.
- Production certification: Huifeng Motors has been certificated according to ISO9001, CSA, TUV, MEPS, CE, UL, CCC,GS, all of our products are made according to RoHS and IEC standard.
| Model | Power | Voltage (V) | Current (A) | Speed (r.p.m) | Eff (%) | Power Factor | Locked rotor torque | Max. torque | Starting Current | Net Weight (Kg) | |
| Rated torque | Rated torque | ||||||||||
| HP | KW | ||||||||||
| ML631-2 | 0.25 | 0.18 | 230 | 1.43 | 2800 | 60 | 0.92 | 1.8 | 1.8 | 7.8 | 5.3 |
| ML632-2 | 0.34 | 0.25 | 230 | 1.91 | 2800 | 63 | 0.92 | 1.8 | 1.8 | 10.8 | 5.6 |
| ML711-2 | 0.5 | 0.37 | 230 | 2.73 | 2800 | 67 | 0.92 | 2.3 | 1.8 | 16 | 7 |
| ML712-2 | 0.75 | 0.55 | 230 | 3.88 | 2800 | 70 | 0.92 | 2.5 | 1.8 | 21 | 8 |
| ML801-2 | 1 | 0.75 | 230 | 5.15 | 2800 | 72 | 0.92 | 2.5 | 1.8 | 30 | 8.5 |
| ML802-2 | 1.5 | 1.1 | 230 | 7.02 | 2800 | 75 | 0.95 | 2.5 | 1.8 | 40 | 9.5 |
| ML90S-2 | 2 | 1.5 | 230 | 9.44 | 2800 | 76 | 0.95 | 2.5 | 1.8 | 55 | 12.5 |
| ML90L-2 | 3 | 2.2 | 230 | 13.67 | 2800 | 77 | 0.95 | 2.5 | 1.8 | 80 | 14 |
| ML100L-2 | 4 | 3 | 230 | 18.2 | 2800 | 79 | 0.95 | 2.5 | 1.8 | 110 | 20.5 |
| ML112M-2 | 5.5 | 4 | 230 | 22.5 | 2800 | 78 | 0.95 | 2.5 | 1.8 | 146 | 32 |
| ML631-4 | 0.16 | 0.12 | 230 | 1.24 | 1400 | 55 | 0.90 | 1.8 | 1.8 | 5.7 | 5.3 |
| ML632-4 | 0.25 | 0.18 | 230 | 1.43 | 1400 | 56 | 0.90 | 1.8 | 1.8 | 8.64 | 5.5 |
| ML711-4 | 0.34 | 0.25 | 230 | 1.99 | 1400 | 62 | 0.92 | 2.5 | 1.8 | 12 | 6.9 |
| ML712-4 | 0.5 | 0.37 | 230 | 2.81 | 1400 | 65 | 0.92 | 2.5 | 1.8 | 16 | 8.1 |
| ML801-4 | 0.75 | 0.55 | 230 | 4.0 | 1400 | 68 | 0.92 | 2.5 | 1.8 | 21 | 8.9 |
| ML802-4 | 1 | 0.75 | 230 | 5.22 | 1400 | 71 | 0.92 | 2.5 | 1.8 | 30 | 9.6 |
| ML90S-4 | 1.5 | 1.1 | 230 | 7.2 | 1400 | 73 | 0.95 | 2.5 | 1.8 | 40 | 13 |
| ML90L-4 | 2 | 1.5 | 230 | 9.57 | 1400 | 75 | 0.95 | 2.5 | 1.8 | 55 | 16 |
| ML100L1-4 | 3 | 2.2 | 230 | 13.9 | 1400 | 76 | 0.95 | 2.5 | 1.8 | 80 | 23 |
| ML100L2-4 | 4 | 3 | 230 | 18.6 | 1400 | 77 | 0.95 | 2.5 | 1.8 | 110 | 27 |
| ML112M-4 | 5.5 | 4 | 230 | 22 | 1400 | 79 | 0.95 | 2.5 | 1.8 | 146 | 35 |
