Mechanical Seal for Water Pump and Motors

Specifications

Mechanical Seal for Water Pump and Motors

1)Mechanical Seal Performance is Stable and Reliable
2)High wear, corrosion resistance
3)fast delivery

APPLICATION:

Mechanical Seals has used in All type of rotating shaft equipment, pumps, mixers, agitators and compressors.

Material:

STATIONARY RING(CERAMIC/SIC/TC)

ROTARY RING(HOT PRESSING GRAPHITE/CARBON/SIC/TC)

SECONDARY SEAL(NBR/EPDM/VITON)

SPRING & OTHER PARTS(SUS304/SUS316)

Material according to Operating Condition, we can offer customer requirement.

Operating Conditions:

Mediums: Water, oil, and general corrosive liquid.

Pressure: ≤ 0.5MPa

Temperature: -20°c˜ 100°c

Speed: ≤ 10m/Sec
