Specifications
CE front end loader*Quick hitch,various optional tools
*New fashion seat
*Adjustable steering wheel
*bucket capacity:0.6cbm
ZL12F front end loader with CE
Specification | overall weight(kg) | 3400 |
L×W×H(mm) | 4900x1650x2600mm | |
rated bucket capacity(m3) | 0.6 | |
Rated load(kg) | 1200 | |
Maximum dump height (mm) | 2750 | |
Bucket indicator | Yes | |
Max. breakout force(KN) | 43 | |
Engine | Model | changchai4L68 |
Type | In-line arrangement, Water cooling, four-stroke | |
Rated power(hp) |
54hp | |
Rated speed(r/min) | 2200 | |
Transmission system | Model of torque converter | YJ240 |
Type | single-phase single-stage radial-inward turbine triplex | |
Gearbox type | Fixed-spindle power shift | |
Gear shift | 2 gears ahead,2 gear astern | |
Hydraulic system | Distribution of work valve | ZL20B |
Working pump | CBGj1045,CBGq1018 | |
Steering system | Type | Articulated hydraulic steering |
Max. turning angle | 27±1° | |
Min turning radius(mm) | 3000 | |
Brake system | Brake type | Oil brake(Vacuum booster) |
Tyres | Standard tyres | 12-16.5 |
Optional wide tyres | 14-17.5 |
