NAKIN High Quality Disc-Type Centrifugal Oil Separator/Marine Heavy Fuel Oil Purification Machine
Application:
The disc-type centrifugal separator (Marin Centrifugal Oil Separator) is mainly used for the purification of the heavy fuel oil in the ship, which can effectively remove the water and impurities from the oil, play a role in the clarification and purification, reduce operating costs and extend the life of the engine. Meanwhile, this machine can be applied to heavy diesel oil, lubricating oil, hydraulic oil, turbine oil clarification and purification to slow wear of diesel engine or other types of machines, and extend the service life of the machine and oil. This machine can also be applied to other areas of non-homogeneous suspensions or emulsions separation.
Features:
1. An ultra-high speed separator to the continuous separation of solid impurities and moisture from the pending purification medium.
2. Automatic trash, continuous and efficient
3. Efficient new heating system, high efficiency, uniform heating.
4. Integrated multi-system, the operation is simple, safe and reliable.
Models of the design, manufacture and acceptance comply with the the disc separator GB/T5745-2002 "marine"
Technical Parameters:
Index |
Unit |
CXJ-1500 |
CXJ-1500A |
CXJ-3000 |
CXJ-4000 |
Flow Rate |
L/H |
1500 |
1500 |
3000 |
4000 |
Seaperating-Factor |
a/g |
7231 |
12094 |
8800 |
9400 |
Running speed |
r/min |
7500 |
8300 |
6300 |
8300 |
Particles |
μ |
2 |
1 |
||
Water content |
% |
≤1 |
|||
Power Supply |
|
380V, 50HZ, 3PH |
|
|
|
Motor Power |
kW |
4 |
4 |
8 |
8 |
Heater Power |
kW |
24 |
24 |
30 |
36 |
Total Power |
kW |
28 |
28 |
38 |
44 |
Sludge-discharge |
|
Manual |
Automatic |
||
Outlet Pressure |
MPa |
≤0.2 |
|||
Weight |
Kgs |
450 |
480 |
850 |
900 |
Dimension |
mm |
1000*750*1100 |
1100*850*1100 |
1000*700*1100 |
1200*900*1200 |
Working Machine:
Customer Visit:
Wooden case Suitable for sea transportation and air transportation
After-sales Service:
One year guarantee for product quality. (People damaged parts are charged).
Lifelong maintenance and spare parts supply.
Free design of fixtures as customers required.
Free training for machines installation and operation of the staffs.
Engineer is available for local installation.
24 months warranty from the delivery time.
24 hours online service question and answer.
