Vacuum Oil Purifier, Oil Recycling, Oil Filtration Machine
Application:
Turbine oil is widely applied in industries, TY vacuum turbine oil purifier is mainly used for purifying unqualified turbine oil, especially for serious emulsion turbine oil, it can quickly and efficiently demulsify, separate water, gas, particles from oil, make sure quality of treated oil to achieve new oil's standard, ensure whole turbine system work safely. This equipment use the special polymer materials as filter medium combined with vacuum separating technology to break emulsification, dewater, degas, remove acid and particles, make the badly turbid turbine oil becomes clear transparent. Series TY is a perfect turbine oil purifier for live line work; also it can purify low viscosity hydraulic oil and lube oil.
Features:
1.Special polymer materials as filter medium with the functions of broken emulsion, dewatering, removing particles;
2.Duplex-Stereo film evaporation technology, equips with unique and advanced dewatering, degassing components, can rapidly and effectively separate water, gas from oil.
3.Multi-stage precision filtration system, mesh filtration combined with molecular adsorption technology.
4.Efficient electric heating system, heating uniformity, less power consumption, safe, and reliable.
5.Double-infrared liquid level sensor, pressure protective system to ensure machine operation easy and safely.
6.Adopt interlocked protective system, which connect oil pump, heater and liquid level sensor, avoiding blank heating, blank pumping, oil leak and electricity leak. If there is any fault, machine will be power off automatically.
7.Work online with stream turbine, hydraulic turbine.
Main Techncial Parameters:
Index Name |
Unit |
TY-30 |
Flow rate |
L/H |
1800 |
Working vacuum |
MPa |
-0.06~-0.095 |
Working pressure |
MPa |
≤ 0.4 |
Temperature range |
C |
20 ~80 |
Demulsifying value |
min |
≤ 15/min(GB/F7035) |
Water content |
ppm |
≤ 80 |
Gas content |
% |
≤ 0.1 |
Cleanness |
|
≤ NAS 6 grade |
Power supply |
|
380V 50HZ 3Ph (As per user's option) |
Working noise |
dB(A) |
≤65~80 |
Heating power |
Kw |
18 |
Total power |
Kw |
20 |
Inlet(Outlet) |
mm |
Φ25 |
Weight |
kg |
500 |
Flow Chart:
1.Each machine packed in one high quality wooden case; The packaging details can follow the customer requierment.
2. Shipping on time according to the customer requierment.
Our After-sales Service:
Engineer is available for local installation.
24 months warranty from the delivery time.
24 hours online service question and answer.
More than 10 years experience
Our Honor and Quality Certificate:
China Famous brand Oil Purifier Company
Golden-supplier for China National Electric power Group
Golden-Supplier for ALSTOM, SIEMENS, SCHNEIDER Company
ISO9001 products quality certificate
CE Products safety certificate
SGS Products local testing report
More than 10 years and 50 countries and districts exporting experience
NAKIN Company is professional vacuum oil purifier/oil filtration, supply various vacuum oil treatment plants, like the transformer oil regeneration machine,online turbine oil treatment, Old lube oil filtration, engine oil regeneration machine in good quality and competitive price.
We provide the features products as following:
ZYD-Double vacuum Transformer oil purifier
ZYM-Movable insulating oil purification cart
AD-Electric transformer air drying equipments
TY-Online Turbine oil treatment
TJ-Fuel oil filtration unit
TYA-Lubricating oil purifier/hydraulic oil purification
JZS-Engine oil regeneration system, waste oil recycling
BZ-Transformer oil regeneration device
PF-Press paper filter machine
JL-Portable oil piurifier,oil filtering,oil filter
BDV dielectric strength tester for transformer oil
NKEE-Oil moisture sensor
