Mobile Vacuum Oil Filtration Plant for Outdoor Recycling Dielectric Oil
Mobile Vacuum Oil Filtration Plant Application:
According to user’s requirements, we developed Series ZYM mobile insulating oil purifier, this machine is mainly used for dealing with unqualified transformer oil, switch oil, mutual inductor oil,, it can rapidly remove water, gas, particles from oil, improving insulating oil’s properties. Besides all functions of series ZYD, the best advantage of ZYM is that can move long distance working in field.
Mobile Vacuum Oil Filtration Plant Features:
1. Mobile (trailer) type, completely closed structure, waterproof, dustproof, move easy.
2. Installation of car tyres, Bridge shock absorber, braking system and steel welding of entire trailer guarantee 60km/h speed.
3. Dealing with unqualified insulating oils, rapidly remove water, gas, particles from oil
4. Multi-stage precision filtration system, mesh filtration combined with molecular adsorption technologies
5. Efficient electric heating system, heating uniformity, less power consumption, safe, and reliable.
6. Double-infrared liquid level sensor, pressure protective system to ensure machine operation easy and safely.
7. Adopt interlocked protective system, which connect oil pump, heater and liquid level sensor, avoiding blank heating, blank pumping, oil leak and electricity leak. If there is any fault, machine will be power off automatically.
Mobile Vacuum Oil Filtration Plant Technical Parameters:
Index name |
Unit |
ZYM-30 |
ZYM-50 |
ZYM-65 |
ZYM-100 |
ZYM-150 |
Flow rate |
L/H |
1800 |
3000 |
4000 |
6000 |
9000 |
Working vacuum |
MPa |
-0.08~-0.099 |
||||
Working pressure |
MPa |
≤0.4 |
||||
Temperature range |
℃ |
20 -80 |
||||
Dielectric strength |
KV |
≥ 70 |
||||
Water content |
ppm |
≤ 3 |
||||
Gas content |
% |
≤0.1 |
||||
Particles size |
μ |
≤1 |
||||
Power supply |
|
380V 50HZ 3Ph (As per user's option) |
||||
Working noise |
dB(A) |
≤65~85 |
||||
Heating power |
Kw |
24 |
30 |
40 |
60 |
90 |
Total power |
Kw |
27.5 |
35.5 |
48.5 |
66 |
105 |
NAKIN Company products list as following:
ZY-high effective vacuum transformer oil purifier, oil filtration
ZYD-Double stages Vacuum insulating/transformer oil purifier, oil treatment, oil purification
ZYM-Mobile/trailer type Vacuum transformer oil treatment, oil filtration machine
TY-Vacuum Turbine oil purifier, oil treatment Plant
TJ-Coalescence and separating light/fuel/gasoline oil filter, oil purifier machine
TYA-Vacuum Lubricating oil purifier/hydraulic oil purification
TYK- Phosphate ester fire-resistant oil purifier, oil filtration machine
JZS-Engine oil regeneration system, waste oil recycling
JZC-Waste Oil Distillation System
JYWL-Horizontal-closed type filtration device
TPF-Waste cooking oil recycling machine
BZ-Transformer oil regeneration device, oil purifier
PF-Plate pressure turbine/transformer/engine/diesel/hydraulic oil filter, oil purifier machine
JL-Portable turbine/lube/insulating oil purifier, oil filtering, oil filter
NKVW-Vacuum pump system
IIJ-II-BDV oil tester, insulating oil dielectric strength tester
NKEE-Oil moisture sensor, water content sensor
