Nakin ZY Single Stage Vacuum Lubricating Oil Purifier
Application:
1. Series ZY high efficiency vacuum insulating oil purifier, mainly for the power station, industrial and mining enterprises purifying the unqualified transformer oil, mutual inductor oil, switch oil and so on.
2. Series ZY can remove water, trace water, gas, particles from oil quickly and effectively, improving oil dielectric strength. Also, this oil purifier can be used to power equipments to vacuum drying, and vacuum oiling.
Features:
1.Duplex-Stereo film evaporation technology, combined with unique and advanced dewatering, degassing components, can rapidly and effectively separate water, gas from oil.
2. Multi-stage precision filtration system, mesh filtration combined with molecular adsorption technologies
3. Efficient electric heating system, heating uniformity, less power consumption, safe, and reliable.
4. Double-infrared liquid level sensor, pressure protective system to ensure the machine operation easy and safely.
5. Adopts interlocked protective system, which connect oil pump, heater and liquid level sensor, avoiding blank heating, blank pumping, oil leak and electricity leak. If there is any fault, machine will be power off automatically.
6. Working with BZ insulating oil regeneration device to decolor (remove acid, oxide, free carbon) and lower dielectric loss, making the treated oil more limpidity.
Advantages:
1. Series ZY is efficient and economical insulating oil purifier.
2. Duplex-Stereo film evaporation technology, unique and advanced dewatering, degassing components, making working efficiency is 3-5 times than traditional oil purifier. Machine adopts interlocked protective system, double-infrared liquid level sensor and pressure protective system to make sure the machine work unattended, operation easy, safe and reliable.
Technical Parameters:
Index name |
Unit |
ZY-10 |
ZY-20 |
ZY-30 |
ZY-50 |
ZY-100 |
ZY-150 |
ZY-200 |
ZY-300 |
Flow rate |
L/H |
600 |
1200 |
1800 |
3000 |
6000 |
9000 |
12000 |
18000 |
Working vacuum |
MPa |
-0.06 - -0.095 |
|||||||
Working pressure |
MPa |
< 0.4 |
|||||||
Temperature range |
C |
20 -80 |
|||||||
Dielectric strength |
KV |
> 65 |
|||||||
Water Content |
ppm |
< 5 |
|||||||
Gas content |
% |
< 0.1 |
|||||||
Particles size |
mm |
< 3 |
|||||||
Power supplier |
|
380v 50Hz,3Ph (As per user's option) |
|||||||
Working noise |
dB(A) |
≤ 65-85 |
|||||||
Heating power |
Kw |
15 |
15 |
15 |
30 |
48 |
60 |
72 |
90 |
Total power |
Kw |
16.5 |
16.5 |
16.5 |
33.5 |
53 |
65 |
76 |
98 |
Product images:
Our Company:
NAKIN Company is professional vacuum oil purifier/oil filtration, supply various vacuum oil treatment plants, like the transformer oil regeneration machine, online-turbine oil treatment, Old lube oil filtration, engine oil regeneration machine in good quality and competitive price.
Packaging:
Each product with one solo wooden case, suiting for transportation. Or packaging as your requirments.
Shipping:
Sea shipping, Land transportation, Air transportation, Express.
After sales services:
1. Engineers are available for local installation.
2. Provided great after sales services within 12 hours.
3. Provided profesional suggestions about oil purifier.
We also provide:
ZYD-Double vacuum Transformer oil purifier
ZYM-Movable insulating oil purification cart
AD-Electric transformer air drying equipments
TY-Online Turbine oil treatment
TJ-Fuel oil filtration unit
TYA-Lubricating oil purifier/hydraulic oil purification
JZS-Engine oil regeneration system, waste oil recycling
BZ-Transformer oil regeneration device
PF-Press paper filter machine
JL-Portable oil piurifier,oil filtering,oil filter
BDV dielectric strength tester for transformer oil
NKEE-Oil moisture sensor
