Help Center(ZY-3000L/D) Flash Point Insulating Oil Filtration Machine
Related Products
-
Power Station Using: Water Evaporation Transformer Oil Recovery FacilityUS$ 6,000 - 13,300MOQ: 1 Unit -
NAKIN Eliminates Water Completely Transformer Oil Purifier,Oil FiltrationUS$ 1 - 12,500MOQ: 1 Unit
-
Electric Heating Type Double-stage ZYD Transformer Oil Filtration MachineUS$ 6,800 - 9,500MOQ: 1 Unit
-
Luxury Insulating Oil Purifier for Power Station and FactoryUS$ 1 - 9,800MOQ: 1 Unit
-
2015 High-Efficiency Vacuum Transformer Oil Clean Purifier(3000L/H)US$ 1 - 20,000MOQ: 1 Set
Specifications
---recover transformer to liquid---doubling vacuum stage,working effective
---adopts heating-up,explosion precaution
ZY Vacuum insulating/transformer oil purifier is mainly for improving oil dielectric strength. The machine can purify water , gas , paricles from transformer oil effectively. And also this oil filtration machine can be used to vacuum oiling and vacuum drying for power equipment. The oil recycling equipment is often used for industrial ,power station, and mining enterprises purifying the unqualified insulating oil ,switch oil etc.
Features:
1.Duplex-Stereo film evaporation technology, combined with unique and advanced dewatering, degassing components, can rapidly and effectively separate water, gas from oil.
2. Multi-stage precision filtration system, mesh filtration combined with molecular adsorption technologies
3. Efficient electric heating system, heating uniformity, less power consumption, safe, and reliable.
4. Double-infrared liquid level sensor, pressure protective system to ensure the machine operation easy and safely.
5. Adopts interlocked protective system, which connect oil pump, heater and liquid level sensor, avoiding blank heating, blank pumping, oil leak and electricity leak. If there is any fault, machine will be power off automatically.
6. Working with BZ insulating oil regeneration device to decolor (remove acid, oxide, free carbon) and lower dielectric loss, making the treated oil more limpidity.
Advantages:
ZY is efficient and economical insulating oil purifier. Duplex-Stereo film evaporation technology, unique and advanced dewatering, degassing components, making working efficiency is 3-5 times than traditional oil purifier. Machine adopts interlocked protective system, double-infrared liquid level sensor and pressure protective system to make sure the machine work unattended, operation easy, safe and reliable.
Technical Parameters:
Index name |
Unit |
ZY-10 |
ZY-20 |
ZY-30 |
ZY-50 |
ZY-100 |
ZY-150 |
ZY-200 |
ZY-300 |
||
Flow rate |
L/H |
600 |
1200 |
1800 |
3000 |
6000 |
9000 |
12000 |
18000 |
||
Particles size |
mm |
< 3 |
|||||||||
Power supplier |
|
380v 50Hz,3Ph (As per user’s option) |
|||||||||
Working noise |
dB(A) |
<=65-85 |
|||||||||
Heating power |
Kw |
15 |
15 |
15 |
30 |
48 |
60 |
72 |
90 |
||
Total power |
Kw |
16.5 |
16.5 |
16.5 |
33.5 |
53 |
65 |
76 |
98 |
||
Working vacuum |
MPa |
-0.06 - -0.095 |
|||||||||
Working pressure |
MPa |
< 0.4 |
|||||||||
Temperature range |
C |
20 -80 |
|||||||||
Dielectric strength |
KV |
> 65 |
|||||||||
Water Content |
ppm |
< 5 |
|||||||||
Gas content |
% |
< 0.1 |
|||||||||
