AD Air Generator Device Oil Filtration Machine
Application
Series AD air generator device oil filtration machine is special for drying the electric equipments and providing the dry air. When operation and maintenance, electrical equipments, such as transformer and reactor, are quite easy to be moistened. Series AD air generator device supplies dry air to solve this problem, anoxia asphyxia will never happen to maintenance people. It’s more safe, reliable, convenient and economical than by using bottled gas. It is not influenced by bad weather conditions, especially for overnight working, just to fill 0.02-0.03MPa dry air into equipment after sealing all flanges. Electric equipments Oil filling and oil drainage is unnecessary, which can shorten working period and improve maintenance effect. During oil filtration, it can fill dry air into oil equipment block and oil to improve oil insulation and decrease the moisture.
Series AD air generator device adopts low pressure oil-less compressed system and low-temperature condensation moisture removal technology, with the merits of small dimension, light weight, easy operation, energy saving and high reliability.
Technical parameters
Model |
AD-5 |
AD-10 |
AD-20 |
AD-40 |
AD-100 |
AD-200 |
Air supply m3/h |
5 |
10 |
20 |
40 |
100 |
200 |
Dew point |
-55℃ to -70℃ |
|||||
Air pressure |
0.02-0.04Mpa |
|||||
Power supply |
380V 50Hz 3Ph |
|||||
Power (KW) |
0.6 |
1 |
2 |
3.5 |
8.0 |
12.0 |
L×W×H(mm) |
800× |
1000× |
1200× |
1400× |
1500× |
1700× |
Inlet/outlet(mm) |
10 |
15 |
25 |
32 |
40 |
50 |
Weight (Kg) |
100 |
160 |
280 |
430 |
720 |
1000 |
Pictures
NAKIN Company is professional vacuum oil purifier/oil filtration, supply various vacuum oil treatment plants, like the transformer oil regeneration machine, online-turbine oil treatment, Old lube oil filtration, engine oil regeneration machine in good quality and competitive price.
We provide the features products as following:
ZYD-Double vacuum Transformer oil purifier
ZYM-Movable insulating oil purification cart
AD-Electric transformer air drying equipments
TY-Online Turbine oil treatment
TJ-Fuel oil filtration unit
TYA-Lubricating oil purifier/hydraulic oil purification
JZS-Engine oil regeneration system, waste oil recycling
BZ-Transformer oil regeneration device
PF-Press paper filter machine
JL-Portable oil piurifier,oil filtering,oil filter
BDV dielectric strength tester for transformer oil
NKEE-Oil moisture sensor
Our company provide good quality machine with competitive price; machine warranty time is 18 months from the delivery date. We can make the specified machine as per user’s options:
1.Trailer type with fully closed for protecting oil purifier machine(Waterproof and dustproof)
2.Choosing different kinds vacuum pump, oil pump, and electric parts.
3.Explosion-proof (EX type) electric parts.
4.Equips moisture sensor and dielectric strength tester on the machine.
5.Filter elements for different requirements on filtering precision
6.Stainless steel material for oil purifier body.
7.Automatic PLC control system
We assure that all materials and equipment being finished under this proposal shall be new and free of defects in workmanship and materials, and shall be of the kind and quality specified in the technical specification. If the purchaser received the goods and discovers defects in workmanship or material and so on, pls notifies the supplier promptly in writing or call, we have the responsibility to provide the new one and technical supports in first time.
As our company dealer, we will provide professional technical learning and support to help this product dealer can better sales and service, to establish our company a good brand image. We invites interested parties to establish a long-term friendly cooperation.
Welcome to inquiry, we all are at your service!!!
