Portable Infrared Imaging Camera Thermal Measuring Instruments

Name: Portable Infrared Imaging Camera Thermal Measuring Instruments
Brand: China Coal
SKU: 143305262
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

China Coal

Model Number:

CC-2

Shandong China Coal Group Co., Ltd. Import &export Branch

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Tianjin Shanghai Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name China Coal

Model Number CC-2

Usage Other, Firefighting

Theory Infrared Thermometer

Accuracy ≤0.1°C@30°C

Temperature Range -20°C-+ 600°C

Product Description

Portable Infrared Imaging Camera Thermal Measuring Instruments Introduction

Features:

1.160*120 uncool FPA detector

2.With temperature measurement function

3.Unique fire-control color palette

4.Apply to fire rescue

5.We are the manufacturer,the price is competitive

6.Portable,small size,lightweight

7.Finding people and identify location in fire place

8.Best after sales service

9.We are the manufacturer,we have price advantage

Items		Technical Specification
Items		CC-2
Detector characteristics	Detector type	Un-cooled FPA micro-bolometer
Detector characteristics	Array size/format	160x120
Image characteristics	Field of view/min focus distance	30°×22.5°
	Spatial resolution(IFOV)	3.3mrad
	Thermal sensitivity	≤0.1°C@30°C
	Frame frequency	50Hz
	Focus	Fixed
	effective distance	≥50m
	Spectral range	8-14um
	Start-up time	≤25s@30°C
Image display	LCD	260,000 color 3.5" TFT LCD, 640x480
Measurement	Temperature ranges	-20°C-+ 600°C
	Measurement type	Fixed spot
	Emissivity correction	Fixed
	palettes	6palettes changeable(black and white, grey and grey inverted, 3 pseudo-color)
Power source	Battery type	(NIMH) battery, rechargeable
	Battery operating time	2 hours continuous operation
	Battery recharge time	≤2 hours
	Battery recharge times	More than 500 times
	Battery charging mode	Intelligent charger
Environment	Operating temperature	-15°C-- +50°C
	Short time operating temperature	+50°C-+260°C
	Storage temperature	-40°C- +70°C
	Encapsulation	IP67(1 meter under water)
	flame retardant rating	UL94-V0
	Drop test	1m
Physical characteristics	Weight	≤1.3kg
Physical characteristics	Dimension	190128273mm
