US$ 120 - 150
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
szret
Model Number:
Motor 57hs09 Driver ND556
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Stepper Motor for Laser Engraving and Cutting MachineUS$ 80 - 120MOQ: 1 Set -
57hs22 and Driver M542, Stepper Motor for Laser Engraving and Cutting MachineUS$ 80 - 120MOQ: 1 Set
-
3 Phase Stepper Motor Driver 3nd583US$ 60 - 70MOQ: 1 Piece
-
Cost-effective 3 Phase Laser Stepper Driver 3nd583US$ 60 - 70MOQ: 1 Piece
-
3 Phase Laser Stepper Driver 3nd583US$ 60 - 70MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
szret
Model Number
Motor 57hs09 Driver ND556
Motor Type
Stepper Motor
Specifications
1stepper motor and driver 57hs09 57hs22 ND5562-phase
3Suitable for a variety of small and medium-sized automation equipment
stepper motor 57hs09 57hs22
Common specifications
Model No. | phase | Step angle | Hold Torque | Rated current | Phase inductance | Phase resistance | Lead number | Rotor inertia | Positioning torque | Weight | Body length |
|
| (°) | N.M | A | mH | Ohm |
| g.cm2 | Kg.cm | Kg | mm |
57HS06 | 2 | 1.8 | 0.6 | 2.0 | 1.8 | 1.4 | 8 | 146 | 0.42 | 0.6 | 55 |
57HS09 | 2 | 1.8 | 0.9 | 2.8 | 1.2 | 0.8 | 8 | 260 | 0.4 | 0.6 | 54 |
57HS22 | 2 | 1.8 | 2.2 | 4.0 | 1.8 | 0.8 | 8 | 460 | 0.7 | 1.1 | 81 |
driver nd556
Electrical Specifications
instructions | unit | min | Typ | max |
Output Current | A | 1.4 | - | 5.6 |
Input supply voltage | VDC | 18 | 36 | 50 |
Control signal input current | mA | 7 | 10 | 16 |
Step pulse frequency | KHz | 0 | - | 400 |
Pulse low time | μs | 1.2 |
|
|
Insulation resistance | MΩ | 500 |
|
|
