Help CenterHigh Quality Promotion 80w Co2 Laser Yueming Power Source
Related Products
-
150w Co2 Laser Power Supply With LCD Intelligent for Laser MachineUS$ 250 - 250MOQ: 1 Piece -
F150 LCD Intelligent Laser Power SupplyUS$ 250 - 250MOQ: 1 Piece
-
F100 LCD Intelligent Laser Power SupplyUS$ 180 - 180MOQ: 1 Piece
-
F80 LCD Intelligent Laser Power SupplyUS$ 180 - 180MOQ: 1 Piece
-
High Quality HY-60T Co2 Laser Power Supply 60w for Co2 Laser Cutting MachineUS$ 130 - 200MOQ: 1 Set
Main feature:
1.This power supply can remarkably reduce spot diameter, and make carving and engraving greater fine.
2. Excellent low power control: This power supply has special advantage for low power control. It can stably control laser power even in
0-7mA. This type new fuction especially is applied for adhesive sticker, score and figure engraving.
3.Easy Control: The start and stop of laser can be easily controlled by TTL level.
4. The power supply has output open circuit protection.
5.This power supply has TTL signal indication, water Through signal indication and laser output indication.
6.This power supply has the BUTTON to test it work properly.
7. Application: Carve and score adhesive sticker. Carve and engrave acrylic, fabric, double-color sheet and rubber.
Yueming Laser Cutting Power Supply 80W
Specification:
|
Input |
Input voltage |
AC198-AC250V or AC99V-AC125V(Please specify when placing order) |
|
AC Frequency |
47-440Hz
|
|
|
Max Input power |
550W
|
|
|
Max Input current |
5A
|
|
|
Output |
Max Output |
Min DC 40KV(AC220V Input,No output load ) |
|
Max Output current |
Min DC 25mA
|
|
|
Efficiency |
Min 88%(Full load) |
|
|
MTBF |
Min 10000 Hours |
|
|
Response time |
Max 1mS(Time from the TTL Signal is given to the output current up to 90% pre-setting current) |
|
|
Withstand Voltage |
Input-Output, Input Enclosure: AC1500V 10mA 60S, Output cathode is connected with enclosure. |
|
|
Environment |
Operating temperature: (-10~40) Centigrade, Relative humidity 90% |
|
|
Cooling |
Force-Air Cooling (FAC) |
|
|
Dimension
|
L*W*H =280*173*97 (mm)
|
|
