Help CenterRD 320 Controller for Co2 Laser Engraving and Cutting Machine
Related Products
-
Hot Sale China Anywell Co2 Laser ControllerUS$ 1 - 400MOQ: 1 Set -
4 Axis Controller for Co2 Laser Cutting and Engraving MachineUS$ 260 - 290MOQ: 1 Set
-
Co2 Laser Engraving and Cutting Controller Leetro Mpc 6515US$ 300 - 410MOQ: 1 Set
-
Co2 Laser Controller Awc608 Leather Cutter PartsUS$ 260 - 290MOQ: 1 Set
-
Colour Display Preview Function Co2 Laser Controller Anywells Awc608cUS$ 350 - 380MOQ: 1 Set
specification
RDLC320 system is a new generation system for control of laser engraving and cutting, which is developed by RD Co., Ltd. In addition to high hardware stability, high voltage or static electricity rejection, and friendly man-machine operation, this system is provided with stronger software function including perfect 3-axle motion control function, large-capacity file storage, two-channel adjustable digits, analog laser power control interface, USB driver of stronger compatibility, multi-channel general/special IO control, and realtime clock and battery integrated for hardware encrypt.
1.1 Laser engraving cutting system introduction
Laser engraving cutting system through a computer numerical control machine tools to achieve effective control, according to the user’s different requirements of the completion of processing tasks.
The system including control board and control panel, and supporting software. This manual describes how to use the software to complete the task of laser processing.( Motherboard wiring and control panel operations, see the accompanying manual and control panel wiring board operating instructions)
1.2 Software supported file formats
Vector format:dxf, ai, plt, dst, dsb…etc.
Bitmap format:bmp,jpg,gif,png,mng,…etc.
1.3 Environmental requirements
1.Windows XP operating system and above, XP recommended.
2.Above CPU586,above PIII or PV recommended.
3. Memory, above 1G recommended
1.1 Comparison of Controller Performance
|
|
Rd310 |
Rd 420 |
Rd320 |
Power Feature |
|
Two-way 5V, independent |
One-way 5V, one-way 24V, independent |
Only one-way 24V (compatible with 36V for power supply, but not recommended) |
Laser port feature |
|
Only one-way digital control port |
One-way digit and one-way analog |
Two-way digits and two-way analog port, settable independently and non-interacted |
Usb feature |
Copying Speed |
Slow |
Common |
Quick |
Compatibility |
Support a few USB disks |
Support USB disks with small capacity |
Support all USB disks with different capacities |
|
Memory feature |
Capacity |
32M |
64M |
256M |
Fault Tolerance |
Poor |
Common |
Capable of checking defective track and formatting and good in fault tolerance |
|
General IO feature |
Input Port |
Nil |
Two ways |
4 ways (two for general, two for specialties) |
Output Port |
Nil |
1-way (low current, so additional drive is needed) |
4-ways (500mA high current for each, OC output, two for general, two for specialties) |
|
Software Feature |
Power-off restart for Engraving |
NO |
YES |
YES |
Online Modification Laser Power/Speed |
NO |
YES |
YES |
|
Multi-origin Logics |
NO |
NO |
YES |
|
Parameter Backup Logics |
NO |
NO |
YES |
|
Work time Preview |
NO |
NO |
YES (the work time accurate to 1ms) |
|
Online Up data Startup Display |
NO |
NO |
YES |
|
Online Up data Main board Program |
NO |
NO |
YES |
|
Motion-axle Feature |
Soft Spacing |
YES |
YES |
YES |
Hard Spacing |
NO |
NO |
YES |
|
Z-axle Linkage |
NO |
NO |
YES |
|
Feeding Feature |
Null |
Single direction |
Single/double direction for option |
|
Power-on Resetting |
Fixed |
Fixed |
Configurable for each axes |
|
Key Speed |
Fixed |
Fixed |
Configurable |
|
Axles |
3 |
4 |
3 (Z axes is configurable to flat or feedin axes) |
