Help CenterRD6332G Color Display Co2 Laser Engraving Machine Controller System
Related Products
-
Anywell AWC708C Co2 Laser Machine ControllerUS$ 1 - 300MOQ: 1 Set -
RD6332M Controller FOR Metal and Non Metal Cutting ControlUS$ 1 - 480MOQ: 1 Set
-
Original Leetro MPC6565 (MPC6535) Laser ControllerUS$ 480 - 500MOQ: 1 Set
-
Ruida RDC6332G CO2 Laser Controller, Laser Cutting and Engraving System, DSP Controller, Controlling Two Laser Heads SeparatelyUS$ 350 - 360MOQ: 1 Set
-
High Quality Co2 Laser Controller PH03US$ 290 - 350MOQ: 1 Set
DSP laser engraving motion control system Parameter
The digital laser control signal
(1) difference output, the TTL level, 20mA driving force
(2) PWM frequency 2.5K~100K adjustable
(3) PWM the dutyfactor 2%~98% adjustable
simulation laser control signal 0~5V automatic followed adjustment
electrical machinery control signal difference output, the TTL level, 20mA driving force
electrical machinery control pulse frequency biggest 500KHZ
USB biggest transmission speed 12M, the most long distance 5 meter
straight line/circular arc /B transect interpolation precision +/-0.5 pulse
4 group general photoelectricity isolates the OC gate output, biggest 600mA driving force
4 group general photoelectricity isolation input, TTL level
Description
The RuiDa technology the RDC6332G controller most remarkable characteristic:
1st, the ethernet (10/100M) and the USB2.0 transmission (the transmission speed is above RDLC320-A product 3 times.);
2nd, the real color TFT screen, can demonstrate the real color on the kneading board the processing graph, simultaneously can on the kneading board the accurate learning laser processing coordinates position;
3rd, can in advance look at the document graph on the kneading board which in the memory preserves, it brushes the screen speed, domestic manufacturer nobody can and;
4th, dynamic demonstration path processing advancement and fiducial mark;
5th, can in operate on the kneading board to revise each chart level directly the processing parameter (for example: The speed, the power and so on), after simultaneously can preserve automatically the revision chart level parameter, prepare the following use (this function other manufacturers to be unable to realize.);
6th, formidable mouse operation support.(Can directly carry on the operation in ours operation kneading board with the mouse, this function other manufacturers are unable to realize, simultaneously this function overseas customer likes extremely.);
7th, the support power failure continues carves, the man-hour looks at in advance (as precisely as a millisecond level, the man-hour in advance looks at the value and the practical work consumes the time to be completely consistent, this function other manufacturers are unable to realize.).
8th, support feeding, fluctuation, revolving carving, about functions and so on push pedal.
9th, the RDC6332G system is the RuiDa technology the technical development the newest generation of laser carving/cutting control system, this control system has the better hardware stability, has a better anti-high-pressured, the anti-electrostatic disturbance characteristic.
10th, based on the LINUX platform development man-machine operating system, has the friendlier operation contact surface and a more formidable function.
11th, this controller use is more perfect the movement control algorithm which, optimizes, its processing speed and the efficiency are before the system is unable and.
Standard carton box and with sponge
Shipping by air or other express like DHL fedex EMS , TNT UPS etc
The shipping also depend on the quanlity that you want .
