Help CenterNew DJQ--II Manual Operation Double-edge Chamfer Machine
Related Products
Specifications
1:ISO90012: The approve of CRCC
Specifications
chamfer machine:
1.chamfering diameter: 32
2.chamfering cutting torque:10KN.M
detailed information :chamfer machine:
1.max.chamfering diameter: Φ32
2.chamfering max. cutting torque: Tmax=10N·m
Our company is a leading manufacturer specialized in variours railway maintenance equipments in China.. Products include rail cutter, rail grinder, rail drilling machine, track lifting and lining machine, railway ballast tamper, railway bolt wrench, rail bender , rail gap adjuster, cutting disc, grinding stone, and etc .Since its foundation in 1992, has provided professional quality service to thousands of units. After years of development, the company has created a wealth of experience in sales and after-sales service team. Customers and users in the formation of a very high reputation. chamfering tool is for eliminating stress concentration of sharp position after drilling rail, it can chamfer on both sides
DJQ-II Double-edge chamfering tool
Scope of application:
DJQ - type Ⅱ bilateral chamfering machine, is to remove the rail special tool Angle place of stress concentration after drilling. With double chamfer, compact structure, convenient operation, small volume light weight, easy to carry, etc. Is necessary and indispensable to the rail drilling tools.
main technical parameter :
1.max.chamfering diameter: Φ32
2.chamfering max. cutting torque: Tmax=10N·m
3.handle max.moving force:Fmax=55N (L=180mm)
ing efficiency: a chamfer/10s
5.dimension:180×50×190
6.total weight: 1.5kg
Feature:
It possesses features of simple structure, reliability, easy manipulation, convenient maintenance,
long lifting range, high hoisting speed and high rail lifting efficiency.
main technical parameter:
main technical data | |
rated lifting force: |
147kN |
rated hook-hoisting force: |
78kN |
lifting range: |
≥270mm |
lifting efficiency: |
127mm/ (once) |
initial height: |
50mm |
crow bar length |
1.5m |
full-loaded max. operating force |
1920N |
overall size |
420×165×522mm |
weight: |
≤25kg |
1.standard package
2. plywood case
3. Delivery Detail: 7-15days after recieving the payment
By GB/T19001-2000 idt ISO9001: 2000 quality management system certification
Our company built up more than ten years received the domestic units of praise and has a high reputation. Our products also export to many countries . We can also design and manufacture according to your requirements.
