Stainless Steel Cutting Wheel,INOX 180*3.0*22.2mm

Stainless Steel Cutting Wheel,INOX 180*3.0*22.2mm thumbnail-1
Stainless Steel Cutting Wheel,INOX 180*3.0*22.2mm photo-1
US$ 0.13 - 0.14 MOQ: 10000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
PEXCRAFT
Shape:
Flat-Shaped
Contact Supplier Request Quote Chat Now
Sichuan Machinery Imp. & Exp. Corp.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hebei, China
Brand Name PEXCRAFT
Shape Flat-Shaped
Abrasive Corundum
Bonding Agent Resin
Hardness Standard
Viscosity Standrad
Size 115x1.0x22.2mm

 Specification



Grinding wheel Product Description

1. High metal removal rate.

2. Less material loss, noise and dust, few sparks.

3. Long-life durability.

4. Low vibration and high stability for comfortable grinding or cutting.

5. 2 sheets of fiberglass for durability and safety,

6. Made by abrasive and special resin, has high tensile, shock and bending strength.

7. Strict quality testing,good after-sale service.

8. Packing : shrink + neutral inner box + neutral carton

9. Accept OEM order for grinding wheel



Abrasives: (A) Aluminium Oxide

Stainless Steel Cutting Wheel,INOX 180*3.0*22.2mm Stainless Steel Cutting Wheel,INOX 180*3.0*22.2mm
Stainless Steel Cutting Wheel,INOX 180*3.0*22.2mm






item inch carton size  inner box size piece/carton
100*3*16 4*1/8*5/8 41X22X22.5 19.7*10.2*10.5 400
100*4*16 4*5/32*5/8 43.5X22.5X22.5 14*10.2*10.5 300
100*6*16 4*2/8*5/8 38.5X22X23 18.5*10.2*10.5 200
115*3*22 4.5*1/8*7/8 43X25.5X13.5 20.7*12*12 200
115*6*22 4.5*2/8*7/8 37X25X26 18*12*12 200
125*3*22 5*1/8*7/8 43X27.5X14.5 20.7*12*12 200
125*6*22 5*2/8*7/8 27X19X28 18*13*13 100
150*3*22 6*1/8*7/8 32.5X23X16.5 16.5*11*16.5 200
150*6*22 6*2/8*7/8 35.5X32X16.5 17*15.3*15.5 100
180*3*22 7*1/8*7/8 38.5X23.5X20 18.5*11*18.5 100
180*6*22 7*2/8*7/8 36X19X20 18.5*17.5*18.5 50
230*3*22 9*1/8*7/8 44X25X25 23.5*10.5*23.5 100
230*6*22 9*2/8*7/8 44X25X25 23.5*8.5*23.5 50



Standard Code of Specifications for wheels
The following table is an example of standard marking system for identifying grinding wheels and other bonded abrasives. For example: A24 RBF.
A 24 R B F
Primary Grains Grain  Size Bond Hardness Bond Type  Reinforcement
A    Brown Aluminium Oxide Coarse    Medium    Fine Soft  Medium  Hard B  =Resinoid Fiberglass
WA White Aluminium Oxide F1   =1 layer
C     Black Silicon Carbide 16/24 /30/36/46/60/80/100/120 N, O, P,  Q,  R, S,T   F2   =2 layers
XA   Excellent Super Grains
AC   Mixed Grains
Snagging Grinding &Cutting  Polishing
    F3   =3 layers
XAC Special Abrasive Grains     F2.5 =2 and half layers

Wheel Configurations

Bonded abrasive wheels have different configurations depending upon the wheel is used on and the desired end result. Below is an example of wheel configuration:

Each wheel configuration is shown on the pages throughout this catalog. The D, T, and B connotations represent the size of the wheel.

   D   Diametet the wheel
   T   Thickness of the wheel
   B   Bore or hole size of the wheel
Stainless Steel Cutting Wheel,INOX 180*3.0*22.2mm Stainless Steel Cutting Wheel,INOX 180*3.0*22.2mm

Recommended Machines

Single-handed angle grinder
100mm, 115mm, 125mm; 500-1400 Watt

Double-handed angle grinder
150mm, 180mm, 230mm; up to 2500 Watt

 Stainless Steel Cutting Wheel,INOX 180*3.0*22.2mm Stainless Steel Cutting Wheel,INOX 180*3.0*22.2mm Stainless Steel Cutting Wheel,INOX 180*3.0*22.2mm

 Stainless Steel Cutting Wheel,INOX 180*3.0*22.2mm





Stainless Steel Cutting Wheel,INOX 180*3.0*22.2mm




2.Productive process
