23m Auger Foundation Pile Drilling Rig

FOB Price

US$ 75,000 - 80,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Rotary Drilling Rig
Power Type	Diesel	Place of Origin	Shandong, China
Brand Name	HW	Usage	Coal
Voltage	220V/380V	Power(W)	110KW
Dimension(LWH)	870023003100MM	Weight	13000KG
Certification	ISO CE	Warranty	1 Year
After-sales Service Provided	No overseas service provided

1. Advanced mobile type, quick to transfer from transportation to working mode.

2.High safety standard, satisfying dynamic and static stability requirements, ensuring safe working

3. Optimized luffing mechanism, working stable, easy to maintenance.

4. Innovative drilling bucket depth measurement system, showing a higher accuracy than

5. conventional pile driver.

6. Bottoming protection and priority control function of main winch, making it easier to operate.

7. Multi-stage of vibration-proof power head, ensuring it working more stable.

8. Mast can adjust vertical property automatically, making it to drill more precise.

9. Humanized cabin design, with large space.

10. Secondary operating interface, more convenient using.

11. Efficient energy-saving turbocharged water-cooled diesel engine.

12. Excellent fuel system

13. Advanced cooling system

14. Intelligent Control System

Size(mm)	8700×2300×3100
Total Weight(kg)	13000(16000)
Drill Depth(m)	1-23
Drill Diameter(mm)	480-1500
Rotary Angle	360degree
Walking speed(km/h)	5-8
Hydraulic System working pressure(mpa)	20-25
Hydraulic system displacement (ml/r)	50/50(63/63)
Engine	Weichai 6105ZLY4
Engine Power(kw)	110
Gear pump model	CBGT 2050/50
