Home > Manufacturing & Processing Machinery > Drilling Rig > Mine Drilling Rig > Down-the-hole (DTH) Blasthole Drill is a Rugged and Time-tested Machine Ideal for Coal or Metal Mining

Down-the-hole (DTH) Blasthole Drill is a Rugged and Time-tested Machine Ideal for Coal or Metal Mining

Down-the-hole (DTH) Blasthole Drill is a Rugged and Time-tested Machine Ideal for Coal or Metal Mining thumbnail-1
Down-the-hole (DTH) Blasthole Drill is a Rugged and Time-tested Machine Ideal for Coal or Metal Mining thumbnail-2
Down-the-hole (DTH) Blasthole Drill is a Rugged and Time-tested Machine Ideal for Coal or Metal Mining thumbnail-3
Down-the-hole (DTH) Blasthole Drill is a Rugged and Time-tested Machine Ideal for Coal or Metal Mining thumbnail-4
Down-the-hole (DTH) Blasthole Drill is a Rugged and Time-tested Machine Ideal for Coal or Metal Mining thumbnail-5
Down-the-hole (DTH) Blasthole Drill is a Rugged and Time-tested Machine Ideal for Coal or Metal Mining thumbnail-6
Down-the-hole (DTH) Blasthole Drill is a Rugged and Time-tested Machine Ideal for Coal or Metal Mining photo-1
Down-the-hole (DTH) Blasthole Drill is a Rugged and Time-tested Machine Ideal for Coal or Metal Mining photo-2
Down-the-hole (DTH) Blasthole Drill is a Rugged and Time-tested Machine Ideal for Coal or Metal Mining photo-3
Down-the-hole (DTH) Blasthole Drill is a Rugged and Time-tested Machine Ideal for Coal or Metal Mining photo-4
Down-the-hole (DTH) Blasthole Drill is a Rugged and Time-tested Machine Ideal for Coal or Metal Mining photo-5
Down-the-hole (DTH) Blasthole Drill is a Rugged and Time-tested Machine Ideal for Coal or Metal Mining photo-6
US$ 14,000 - 30,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, DTH drilling rig
Power Type:
Diesel
Contact Supplier Request Quote Chat Now
Shandong Hengwang Group Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, DTH drilling rig
Power Type Diesel
Place of Origin Shandong, China
Brand Name HWZG
Model Number HWZG-500
Usage Water Well
Voltage 220V/380V
Power(W) 15KW
Dimension(L*W*H) 2700*950*1770mm
Weight 1150kg
Certification ISO9001
Warranty 12 Months
After-sales Service Provided Engineers available to service machinery overseas
Product Description

Main Features


Down-the-hole (DTH) blasthole drill is a rugged and time-tested machine ideal for coal or metal mining

HWZG hydraulic down-hole drilling rig is a multi-functional drill rig driven by internal combustion engine, the drilling power was provided by hydraulic system except for impacting and the hole cleaning wind. It is convenient and efficient to operate. This drill is the best replacement for traditional pneumatic drills in most operation. The drill is compact in structure, simple in operation, light in total weight. HWZG hydraulic crawler drilling rig is widely used for blast-hole drilling in the mines and quarries. It is also used for anchor in road, railway, power station, civil engineering and building etc.


Technical Parameters
1
Machine Model
HWQ-500
Unit
2
Max.drilling depth
500
m
3
Drilling diameters
105-400
mm
4
Air pressure
1.05-3.45
Mpa
5
Air consumption
16-55
m3/min
6
Rod length
3
m
7
Rod diameters
102
mm
8
Main shaft pressure
12
T
9
Lifting force
25
T
10
Fast lifting speed
25
m/min
11
Fast forwarding speed
35
m/min
12
Rotary torque
9000
NM
13
Rotary speed
75/150
r/min
14
Big secondary winch lifting Force
2.5/4
T
15
Small secondary winch lifting force
1.5
T
16
High leg stroke
1.6
m
17
Drilling efficiency
10-35
m/h
18
Moving speed
3
Km/h
19
Clambing capacity
21
°
20
Weight
11
T
21
Dimension
6.8*2.25*2.85
M
22
Working condition
Hard Rock
F > 6-20
Detailed Images



Customer Visit
Certifications
Our Company

Shandong Hengwang Heavy Industry co.,ltd is the professional manufacturer of Pile driver,Drilling rig,Road construction machine . With more than 300 workers and 25 Senior engineers,high quality products and best after sales service can both be guaranteed. main clients are around Southeast Asia,Mid East and South America. Welcome visit our factory and sent inquiry to us.
