Product Details
Place of Origin: | Hebei, China | Brand Name: | JNDL | Model Number: | JNDL001 |
Type: | Insulated | Application: | Overhead | Conductor Material: | Aluminum |
Conductor Type: | Other, Stranded, Solid | Insulation Material: | Other, Fiberglass, Fiberglass |
Product Description
Electric Security Tools - Grounding Equipment Sets
Temporary Earthing sets
1.Combined by phase lead, earth lead, earth bar and earth end clamp.
2.Product it as your request
Electric Security Tools
1.Product characters: the hook adopts light aluminium alloy compression casting, pole use the light epoxy manufacture, hight strength, excellent ability of electric conduction. Baling wire uses electrolysis copper wire. The temperature scope for protective cover: ±40°C
2.Product specification: cross area of earthing wire 16mm2 , 25mm2 , 35mm2 , 50mm2 , 70mm2 . Also can produce it as your request.
3.Applications: A distribution lines and systems
B transmission lines and systems
C substation bus
D underground systems
F industrial circuits and systems
Electric Security Tools
Applications:
1>. Distribution lines and systems
2>.Transmission lines and systems
3>.Substation bus
4>.Underground systems
5>. Industrial circuits and systems
Specifications:
Model | Length | Number | Size of earthing wire | Withstand Voltage (KV) |
JT-1901 | 1m | 3 rods/set | 25 m2 | 10KV |
JT-1915 | 1.5m | 3 rods/set | 25 m2 | 35KV |
JT-1902 | 2m | 3 rods/set | 35 m2 | 110KV |
JT-1903 | 3m | 3 rods/set | 35 m2 | 220KV |
JT-1904 | 4m | 3 rods/set | 35 m2 | 220KV |
Suitable for making power failed equipments or temporary short-circuited lines grounded, preventing unexpected power to intrude in and do damage to personnel and equipments.
