2014 New SINOTRUK HOWO Man 6x4 Tractor Truck for Sale

Name: 2014 New SINOTRUK HOWO Man 6x4 Tractor Truck for Sale
Brand: sinotruk howo truck
SKU: 143067982
Availability: InStock

US$ 30,000 - 50,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Horsepower:

251 - 350hp

Drive Wheel:

6x4

Jinan Sinoauto Heavy Duty Truck Sales Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao tianjin shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Horsepower 251 - 350hp

Drive Wheel 6x4

Transmission Type Manual

Emission Standard Euro 2

Fuel Type Diesel

Brand Name sinotruk howo truck

Size 6800x2496x2958

Gross Vehicle Weight 25

Specifications

2014 new SINOTRUK HOWO man 6x4 tractor truck for sale
1. front axle: HF7
2.tyre: 12.00-20
3. engine: WD615.87
4. cab: HW76

2014 new SINOTRUK HOWO man 6x4 tractor truck for sale

detailed diameter:

Truck modle		ZZ4257M3241W
Type front axle6800x	HW76
Style	Lengthen cab, single sleeper, ajustable, steering wheeVDOinstrument and control modle, safety belt, sunshade on the outside
Type	WD615.87
Rated power kW/rpm	213/2200
Max torque Nm/rpm	1160/1100-1600
emission L	9.726
Style	In-line, six clyinder engine, inter-cooling, supercharger in the rear
Clutch		WD615.47,D12.38 with D12.42engine with 430A,WD615.69 with 430B,WD615.62,WD615.87with 430C
transmission		SINOTRCK HW series 10 transmission, the structure of main box and gear box, WD615.62,WD615.87,WD615.69 with HW15710,WD615.47 with HW19710
Front axle		HF7 the style is drum,rated weight 7t
Drive axle		HW1667,standard 3.73,optional 4.22
suspension		Front axle is steel spring,which with shock absorber and the horizontal stabilizer
Turning system		ZF8098
Eletric system		voltage:24V;engine :1540W;starter:24V,7.5kW; accumulator:2×12V/165Ah
tyre		12.00-20; optional 11.00-20
Fuel tanker volume L		400
Curb weight kg		9180
Gvw kg		25000
Trailer total weight kg		32400
Max Saddle weight kg		15690
Dimension mm		6800×2496×2958
Wheel base mm		3200+1400
Front/rear overhang mm		1500/725
Track (front/rear) mm		2022/ 1850
Min ground clearance mm		267
Approaching/departure angle		16/70
Max speed km/h		102
Max grade ability %		20
Min turning diameter m		15
Saddle ground clearance mm		1360/1326
Front/rear turning radius mm		2790/2230
Towing pin		50#(2 hour)
Remark		Optional WD615.62
