Air Hammer C41-40

SJR Machinery Co., Ltd.
Air Hammer C41-40 thumbnail-1
Air Hammer C41-40 photo-1
US$ 1,000 - 50,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
SMAC
Model Number:
C41-40
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name SMAC
Model Number C41-40
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Easy to operate down, single blow, light or full series blow can be obtained as desired

Specifications

Air Hammer C41-40



This pneumatic hammer is widely used for general Forging works, such as drawing-out, upsetting,punching, chiseling, forge, welding, bending and twisting. It is also used for forgn in bolster dies.



Ready operation: economic and converient



Easy to operate down, single blow, light or full series blow can be obtained as desired



A special oil-pump is provided for lubricating the cylinders. Prior to running, turn the hand-crank of the pump to get the cyliders being lubricated beforehand.



One piece, two piece designed avaiable.


1)Low noise ,reasonable structure , convenient operation.
2)Suitable for all kinds of forging works.



Features

1) Applications: a) Widely used for general forging works, such as drawing- out, upsetting, punching, chiseling, forge, welding, bending and twisting b) Also used for forge in bolster dies

2) Ready operation: economic and converient

3) Easy to operate down, single blow, light or full series blow can be obtained as desired

4) A special oil-pump is provided for lubricating the cylinders

5) Prior to running, turn the hand-crank of the pump to get the cyliders being lubricated beforehand

6) One piece, two piece designed available



Main parameters



Model
Unit
12001
12002
12003
12004
12005
12006
12007
12008
12009
12010
Specification

C41-25
C41-40
C41-75B
C41-150
C41-250B
C41-400B
C41-560B
C41-750B
C41-1000
C41-2000
Rated weight of the tup
kg
25
40
75
150
250
400
560
750
1000
2000
Maximum single hit energy
kg
275
0.53
1.0
2.5
5.6
9.5
13.7
19
27
54
Hit Number
min'1
250
245
210
180
140
120
115
105
95
80
Tupaxis to frame front
mm
260
235
280
350
420
520
550
750
800
950
Forges
Square
mm
40x40
52x52
75x75
130x130
145x145
220x220
270x270
270x270
320x300
350x350
workes
Round
mm
45
68
85
145
175
240
280
300
320
400

Type

Y132M
Y132M1-6
Y160M-6-B3
Y180M-4B3
Y180L4-B3
Y200L4B3
Y280S-6-B3
Y280M-6-B3
Y280M-6-B3
Y315L2-6-B3

Power
kw
2.2
4
7.5
18.5
22
30
45
55
75
132

Hammer
kg
470
710
2500
3260
5000
8000
9800
17000
20000
48000

Anil block
kg
250
420
950
1500
2500
4800
6720
9000
13000
24000
Outside size
mm
800x410x1214
1400)600x1500
1480x1355x1853
2390x1085x2150
2639x1000x2540
2789x1400x2884
3646x1500x3157
3905x1370x3175
4105)6750x3200
4200x2300x4390





Our service



1.OEM



2.Spare parts



3.Warranty for one year



4.Tech support is available for 24 hours



5.Fast delivery



Company Information

Found in 1984 Our Smac Machine Tool Co., Ltd as the main partner member of China Jiangsu International Economic-Technical Cooperation Corporation. specializes in import& export of brand-new industrial machinery & tools. Our mechanical products cover more than 80 kinds including lathe, milling machine, grinding machine, power press, hydraulic guillotine, hydraulicpress brake, CNC & automotive machines and so on, which have been exported to 50 or more countries & areas.

 SMAC Machine Tool Co., Ltd is proud to be the professional, high reputation company with high-qualified & professional staff, competive prices and quick & thoughtful after-sale service to cooperate with you.
