JL31-800A Straight Side One Point Press Machine
US$ 10,000 - 20,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New, New
CNC or Not:
Normal, Normal
Power Source:
Other, Mechanical, Mechanical
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
JL36C-630Y Straight Side Two Point Press MachineUS$ 10,000 - 20,000MOQ: 1 Set -
Friction Press for Best SaleUS$ 1,000 - 10,000MOQ: 1 Set
-
Air Hammer for Hot SaleUS$ 8,000 - 15,000MOQ: 1 Set
-
High Precision Friction PressUS$ 1,000 - 10,000MOQ: 1 Set
-
Stroke Adjustable Strong Steel Frame Press MachineUS$ 5,000 - 15,000MOQ: 1 Set
Power Source
Other, Mechanical, Mechanical
Place of Origin
Zhejiang, China
Brand Name
SMAC, SMAC
Model Number
JL31C-800A, JL31-800A
Voltage
380V, 220V/380V
Power(W)
75000W, 75Kw
Weight
106t
Certification
ISO
Warranty
1 year
After-sales Service Provided
Engineers available to service machinery overseas
Product Description
JL31-800A Straight Side One Point Press machine
Features:
- The base, uprights, cross-beam and slide, which are all welded structure, positioned by positioning bushing and connected through hydraulic pretightening force bolts .
- Triple drive mechanism, one is belt drive, and the two are gear transmission (160T double driven system).
- Adopt mechanical system and digital cam to control operation condition.
- Rods and slide connected through guide pillars and bushes, which have eight guide rails.
- Introduce low inertial clutch brake, and imported safe double valve to control;
- The slide adopts hydraulic overload protecting device, which controlled by imported pump valve; Die height adjusts automatically;
- Lubricating system include thin oil circulating lubrication and dense oil regular lubrication, which are fix quantify and time ,also with high and low oil levels detection;
- Hydraulic ,pneumatic components and electrical controllable elements are all introduce fine quality brand name products;
- Adopt pneumatic cushions or hydraulic supercharging cushions;
- Electrical system introduces PLC double loop control;
- With Oil levels detection, and failure testing, all actions are interconnect;
- Dedicated vibration isolators are optional, which could reduce shock and vibration and prolong press and die service life;
- Assist equipments are optional ,such as uncoiler, leveller, feeder, shears ,blanker, Robot Palletizer,and etc.
Main parameters
| Model | 11401 | 11402 | 11403 | 11404 | 11405 | 11406 | 11407 | 11408 | 11409 | ||
| Unit | JL31C-630B | JL31-630T | JL31C-800 | JL31-800A | JL31-800B | JL31C-800 | JL31C-1000B | JL31-1250 | JL31-1600 | ||
| Nominal force | KN | 6300 | 6300 | 8000 | 8000 | 8000 | 8000 | 10000 | 12500 | 16000 | |
| Nominal force stroke | mm | 13 | 13 | 13 | 13 | 13 | 13 | 13 | 13 | 13 | |
| Stroke of slide | mm | 400 | 400 | 500 | 300 | 300 | 300 | 350 | 500 | 500 | |
| Strokes per minute | spm | 12 | 12 | 10 | 12 | 20 | 12 | 12 | 10 | 10 | |
| Max.die set height | mm | 700 | 700 | 800 | 550 | 600 | 600 | 700 | 800 | 1400 | |
| Die height adjustment | mm | 250 | 250 | 315 | 200 | 100 | 200 | 250 | 300 | 500 | |
| 250Size of table | L-R | mm | 1700 | 1700 | 1900 | 1900 | 1400 | 1400 | 1800 | 1800 | 1800 |
| F-B | mm | 1500 | 1500 | 1600 | 1600 | 1200 | 1200 | 1600 | 1600 | 1600 | |
| Bottom size of slide | L-R | mm | 1680 | 1430 | 1800 | 1860 | 1400 | 1400 | 1800 | 1800 | 1800 |
| F-B | mm | 1400 | 1400 | 1500 | 1500 | 1200 | 1200 | 1600 | 1600 | 1600 | |
| Distance between gibs | mm | 1720 | 1520 | 1830 | 1830 | 1530 | 1530 | 1860 | 1880 | 1910 | |
| Cushion | Clamping/Ejecting force | KN | 500 | / | 800 | 300 | 150 | 350 | / | 1500/500 | 700 |
| Number | 1 | / | 1 | 1 | 1 | 1 | / | 1 | 1 | ||
| Stroke | mm | 200 | / | 250 | 200 | 100 | 150 | / | 250 | 250 | |
| Overall dimensions | L-R | mm | 3950 | 4655 | 4350 | 4960 | 4685 | 48010 | 4400 | 4900 | 6600 |
| F-B | mm | 3350 | 3220 | 3270 | 3945 | 3645 | 3600 | 3650 | 4100 | 4800 | |
| Height above floor | mm | 7870 | 7735 | 8300 | 7700 | 7750 | 7550 | 8900 | 9400 | 9980 | |
| Air pressure | MPa | 0.55 | 0.55 | 0.55 | 0.55 | 0.55 | 0.55 | 0.55 | 0.55 | 0.55 | |
| Main motor power | KW | 75 | 75 | 75 | 75 | 75 | 75 | 90 | 110 | 132 | |
| Total weight | T | 98 | 92 | 125 | 116 | 110 | 106 | 150 | 210 | 300 | |
