Lathe Machine

Name: Lathe Machine
Brand: SMAC
SKU: 143010054
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Turning Center

CNC or Not:

CNC

SJR Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Turning Center

CNC or Not CNC

Place of Origin Guangdong, China

Brand Name SMAC

Model Number C6240C

C6240C Gap lathe/lathe/lathe machine/cnc lathe

Optional Accessories:
Steay rest
Follower rest
4-jaw chuck
Face plate

Standard Accessories

3-jaw chuck

Center & center sleeve

Wrenches

Oil gun

Item		C6^1/236C	C6^1/240C	C6^1/250C
General capacity	Max.swing over bed	360	400	500
	Max.swing over cross slide	190	230	330
	Max.swing over gap	520	560	660
	Center distance	750,1000,1500mm
	Bed width	3600mm
Main spindle	spindle hole	52mm
	Spindle nose	C6
	Spindle taper	MT6
	Spindle speeds(Number)	40-1400rpm(9 Steps) 1600rpm
Feeds	Metric threads range(Kinds)	0.24-14mm(19 Kinds)
	Inch threads range (Kinds)	2-40/inch
	Moudle threads range(Kinds)	0.5-3.5mm(11Kinds)
Carriage	Cross slide travel	180mm		222mm
	Compound rest travel	95mm
	Cross-section size of toolshank	20x20mm²
Tailstock	Taper of tailstock sleeve	MT4
	Diameter of tailstock sleeve	65mm
	Travel of tailstock sleeve	140mm
Main motor power		4kw		5.5kw
Packing size(L x W x H)
Center distance:750mm		2220x1150x1590mm
1000mm		2470x1150x1590mm
1500mm		2970x1150x1590mm
Net weight/Gross weight(Kgs)
Center distance:750mm		1350/2000	1400/2050	1500/2150
1000mm		1450/2100	1500/2150	1600/2250
1500mm		1600/2250	1650/2300	1750/2400
