reconnaissance robot for rescue and inspection
- 10 Piece / Pieces per Month
- Xingang
- T/T Credit Card
Product Details
Place of Origin: | Beijing, China | Brand Name: | TOP SKY | Model Number: | RXR-C7BD |
Product Description
reconnaissance robot RXR-C7BD for rescue and inspection
Overview:
The fire reconnaissance robot can enter the chemical dangerous goods warehouse, large underground space, collapsed building, petrochemical area and other disasters area to have real time acquisition, processing and transmission of the real time images, data and voice. It can keep the firefighters out of danger. The fire reconnaissance robot is powered by Lithium battery, equipped with all-terrain track. It can easy go across the stairs or ditches. The robot is also equipped with environmental monitor, wireless image acquisition, transmission and storage equipment which are high integration, easy to operate and safety.
Application:
It can be used in Public road or railway tunnel fire; underground facilities or warehouse fire; large space fire area; petrochemical depot fire; large toxic or smoke accident; the investigation of hazard fire and so on.
Functions:
Environmental monitoring including temperature, humidity, thermal radiation, nuclear radiation, toxic gas concentration monitor; combustible gas monitor ( Different sensors can be optional according to need)
Wireless video device including HD surveillance camera( with PTZ and night vision), traffic cameras and wireless video transmission device.
Background monitor which can allow remote control within 200m .
Specification:
Robot body | |
Weight(kg) | ≤120 |
Size(mm) | L960×W680×H320 |
structure: | Frame+Independent suspension design+Six shock spring design |
Material | Independent suspension all-metal design,ensure good performance of affixing to ground, enhance off-road performance |
Ground clearance(mm) | 115 |
Gradeability(°) | 45(Can climb stairs) |
Chassis height(mm) | 85 |
Maximum obstacle(mm) | 220 |
Maximum span(mm) | 480 |
Wading depth(mm) | 200 |
Speed(km/h) | 0-6(CVT) |
Working lights | 30W LED light |
Design load(kg) | 100 |
Endurance capacity(H) | 2 (Continuous running) |
remote control distance | ≥200m |
Measuring of environmental parameters | |
Gas | |
CO | 0-1000ppm |
NO2 | 0-50ppm |
H2S | 0-100ppm |
NH3 | 0-100ppm |
SO2 | 0-60ppm |
CH4 | 0-10ppm |
O2 | 0-25% |
Temperature,wind speed,humidity | |
Temperature | -20-100℃ |
Wind speed | 0-30m/s |
humidity | 0-100%RH |
Radiant heat |
|
Detection range | 0-20kw/m² |
X, γ-ray detector |
|
Detection range | 0.01~5000 uSv/h |
Detector | Thin-walled GM counter |
Energy range | 40KeV~3MeV |
Sensitivity | ≥3000CPM/mR/h |
Relative error | ≤15% |
Video | |
Image Sensor | 1/4" CCD |
Effective Pixels | 752(H)×582(V) |
Synchronous System | Internal Synchronization |
Certificate: explosion-proof certificate Through the National Fire Equipment Quality Supervision and Inspection Center test Manufacturer Qualification Registered capital of 40 million RMB Passed the ISO9001 certification Passed ISO14001 environmental management system certification
|
