Specifications
Jet Pump,be suitable to convey clean water and non-agressive chemical fluids.Jet Pump Specification
Operating conditions:
1. ing pressure 8 bar
2. Liquid temperature up to 60ìC
3. Ambient temperature up to 40ìC
4. Total suction lift up to 9m
5. Continuous duty
Motor:
1. Two-Pole induction motor(n=2900r.p.m.)
2. Insulation Class B/F
3. Protection IP44
Material:
1. Pump body: Cast Iron
2. Motor Support: Cast Iron
3. Impeller: Brass/Noryl
4. Diffuser: Noryl
5. Shaft with rotor: Hi-Cr plated 45# Steel/Stainless Steel
6. Mechanical seal: Carbon/Ceramic
Application:
-Self priming jet water pumps with a very high hydraulic performance and a considerable pressure capacity.
-Able to pump up to mt.9 depth and work perfectly even in soda-water
-Suitable for water lifting and distribution in domestic fittings by small and medium sized tanks.
Model | Power | Max.Flow(L/min) | Max.Head(m) | Max.Suct.(m) | Inlet/Outlet(inch) | G.W./N/W. | Packing size(mm) | QTY/20”CTR(pc) | |
KW | HP | ||||||||
JSP60 | 0.37 | 0.50 | 40 | 35 | 9 | 1”X1” | 16/15kg | 420X205X235 | 1400 |
JSP80 | 0.55 | 0.75 | 50 | 40 | 9 | 1”X1” | 16/15kg | 420X205X235 | 1400 |
JSP100 | 0.75 | 1.0 | 60 | 45 | 9 | 1”X1” | 16/15kg | 420X205X235 | 1400 |
