Cast Iron Garden Jet Pump for garden irrigation
Our pressurized water booster pump is perfect for transferring water from wells or water reservoirs up moderate slopes and to upper stories of buildings. This water pressure booster pump gives homes up to 5 times more pressure in their water pipes for better showers, cleaning and irrigation. 1.5 horsepower motor pumps 925 gallons per hour and has a max lift of 150 feet. This pump is perfect for draining, adding water pressure to houses and farm irrigation.
But shall not be suitable for long time continuous operation (e.g. cyclic running in filter of swimming pond or act as industrial equipment).
Operating conditions:
1. ing pressure 8 bar
2. Liquid temperature up to 60ìC
3. Ambient temperature up to 40ìC
4. Total suction lift up to 9m
5. Continuous duty Cast Iron Garden Jet Pump
Motor:
1. Two-Pole induction motor(n=2900r.p.m.)
2. Insulation Class B/F
3. Protection IPX4
Material:
1. Pump body: Cast Iron
2. Motor Support: Cast Iron
3. Impeller: Brass/Noryl
4. Diffuser: Noryl
5. Shaft with rotor: Hi-Cr plated 45# Steel/Stainless Steel
6. Mechanical seal: Carbon/Ceramic
Application:
1.Self priming jet water pumps with a very high hydraulic performance and a considerable pressure capacity.
2.Able to pump up to mt.9 depth and work perfectly even in soda-water
3.Suitable for water lifting and distribution in domestic fittings by small and medium sized tanks.
Technical Data:
Model |
Power |
Max. Flow
(L/h)
|
Max.Head
(m)
|
Max.Suct.
(m)
|
Inlet/Outlet
(inch)
|
G.W./N.W. |
Packing size
(mm)
|
QTY/20CTR
(pcs)
|
|
KW |
HP |
||||||||
TP6002JF |
0.6 |
0.75 |
2800 |
35 |
8 |
1X1 |
9/8.5kg |
375x210x260 |
1400 |
TP8002JF |
0.8 |
1.0 |
3200 |
40 |
8 |
1X1 |
10/9.5kg |
375x210x260 |
1400 |
TP10002JF |
1.0 |
1.25 |
3500 |
44 |
8 |
1X1 |
11/10.5kg |
375x210x260 |
1400 |
TP12002JF |
1.2 |
1.50 |
3800 |
50 |
8 |
1X1 |
12/11.5kg |
375x210x260 |
1400 |
