2013 Hot Sale Powerful Pionjar 120 Gas Power Rock Drill YN27C

Specifications

YN27C Gas Power Rock Drill :
1.Professional Manufacturer
2.CE/ISO9001
3.Multiple functions
4.Best price

2013 Hot Sale Powerful Gas Power Rock Drill For Mine





YN27C Gasoline Rock Drilling a very efficient machine,composed of gasoline engine, Air pump, rock drill. It adapt to these outside situations without water and electronic power. Meanwhile it is a hand- held drill, during operation,rock power is blown away by the compressed air produced by the machine itself. .Its suited to work on high mountains, plains, hot and cold area with no power and no water supply and air compressing equipments, and especially suits the projects that the machine has to be carried at any time and in any area.





Features:



1. Easy to operate

2. Time and labor saving, Drilling fast and high efficiency.
3. has wide adaptability for high mountain and plain, extreme temperature (40 to -40)
4. Used for vertical downward hole (max depth 6m) and and <45°upward hole.
5. Light Weight, only 27kgs, easy for carrying





 Specifications



Weight of main machine	27kg
Overall dimensions(L*W*H)	746*315*229mm
Cylinder diameter*stroke of piston	Φ58*70mm
Rotation speed of engine	≥2450rpm
Displacement of engine piston	185cm³
Type of carburetor	hand needle valve, floatless type
Ignition system	controllable silicon, contactless system
Drilling speed (mean value of five holes)	≥250mm/min
Drilling hole diameter	Φ28-42mm
Max drilling depth	6m
Fuel consumption	≤0.12L/m
Tank capacity	≥1.5liter
Drill rod and breaker shank	Hex22*108mm
Rotating speed of drill rod	≥200rounds/min
Clearance of spark plug	0.5-0.7mm







Photos:





Spare Parts:









Small Catalogues:







Welcome to enquiry ,we have many kinds of rock drill jack hammer.
