Specifications
Wire Saw machine for mining1.For quarrying use of any type stone
2.Factory directly sell
3.Easy use
Wire Saw machine for mining
Variable wire speed range from 0-40M/S
- automatic step-less tensioning system to keep the wire always in optimal working condition
- angle adjustment range from 0- 360degree
- horizontal extension of flywheel shaft position +/- 350mm
- backward speed of machine without loading range from 0-700mm/minute
- safety stop in case of unexpected wire breakage or other faults Diamondwi
| Technical Data/Type | DSL-75G-10P |
| Driving Power (KW) | 75kw(100HP) |
| Diameter of Flywheel (mm) | 1000 |
| Wire Saw Speed (m/s) | 0-40 |
| Length of Wire (m) | 20-150 |
| Feeding Power (Kw) | 1.5 |
| Sideways Range (electric driving) (mm) | 650 |
| Rotation Angle (electric driving) | 360° |
| Moving speed of Machine (m/h) | 0-32 |
| Length of Rail | 2mx3+1m |
| Power (AC V/HZ) | 380/50 |
| Allowable Working Temperature °C | -15~+40 |
| Machine Weight (Ton) | ~3.3T |
Other type of wire saw machine:
| Main Motor Power | Length of Wire (m) | Linear Speed (m/s) | Diameter of Flying Wheel | Remark |
| 22KW | 5-40 | 0-40 | 800mm | For quarrying use of any type stone |
| 37KW | 20-80 | 0-40 | ||
| 45KW | 20-100 | 0-40 | ||
| 55KW | 20-120 | 0-40 | ||
| 75KW | 20-150 | 0-40 |
Pictures of wire saw machine
