Hydraulic Water Hole Boring Machines

Fuzhou Dig Sword Land Machine Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New, New

Type:

Other, Core Drilling Rig, core drilling rig

Power Type:

Gasoline

Payment & Shipping

Payment Methods:

Port of Shipment:

Fuzhou or other port from China

Delivery Detail:

Delivery time depends on order quantity.

Type Other, Core Drilling Rig, core drilling rig

Power Type Gasoline

Place of Origin Fujian, China

Brand Name DSL

Model Number water well drilling rig

Usage Water Well

Certification CE

After-sales Service Provided Overseas third-party support available

Specifications

1.Similar to good brand
2.Well design below to factory,low price.
3.Drilling depth:180m
4.With CE-Approved

hydraulic water hole boring machines

The application scope about this water well

Used for general investigation, geophysical exploration, high-way and building construction, and blast-hole drilling etc.
With hydro-automatic feeding device, and high drilling efficiency.
Designed with hydro-chucking unit instead of slips to ensure drilling from stop when changing pipes.
Close levers, convenient to operate, safe and reliable operations.
Compact in structure. All the drill, water pump and diesel engine installed on one base frame result in space-saving.
Light in weight, easy disassembling for transportation and applicable to working conditions in plain and mountain areas.

The specification of this water well

Specifications
Unity machine parameter
Drilling depth		100 180m
Drill rod caliber		50 42mm
End hole caliber		75 46mm
Maximum open hole caliber		220mm
Drilling angle		90°~75°
Unity machine dimensions		2.1×0.9×1.3m
Drill weight (No include power)		610kg
Spindle
spindle speed		130 300 480 730 830 1045r/min
Spindle stroke		450mm
Hoist
Max.single line hoisting capacity		11KN
Single line lifting speed		1.06 0.67 0.32m/s
Tightrope caliber		9.3mm
Tightrope cubic measure		35m
Hug floodgate belt width		50mm
Hug floodgate caliber		240mm
Mud pump
Type	Horizontal single urn twin-action
Displacement	95 77L/min
Diesle engine	s1105 18HP
Electric motor	Y160M—4 11KW
Maximum pressure	1.2Mpa
Work pressure	0.7Mpa

Some picture about this water well

The specification of other relation water well

Model	SM-100Y	SM-130Y	SM-180Y	SM-200Y
Drilling depth	100m	130m	180m	200m
Maximum open hole diameter	200mm	220mm	220mm	300mm
End hole caliber	75mm	75mm	75mm 46mm	75mm
Drill rod caliber	50mm	50mm	50mm 42mm	60mm
Drilling angle	90°~75°	90°~75°	90°~75°	90°~75°
Drill weight(No include power)	480 510kg	560kg	610kg	975kg
