Specifications
Solar thermal vacuum tube soalr collector1.EN12975 solar keymark
2.Anti-freezen & pressurized
3.10 years warranty
Solar thermal vacuum tube solar collecotr
a. Module design, arbitrary combination, harmonize with the building perfectly
b. Intelligent control and automatic operation
c. Anti-freeze: Using the anti-freezing liquid as the medium and the controller
has
the anti-freezing function
d. Multifunction: bathing, washing, domestic heating etc.
e. Work at anytime and enjoyable.
Material of Model:
1) The pipeline is made of red copper and conducted by heat transfer medium
liquid
2) Temperature preservation is equipped with standard electric water heater
setting,
automatic temperature control exchanger, and increased anode magnesium bars
sticking to prevent furring
3) The insulating layer uses polyurethane bulk bubble and has a good effect of
temperature preservation
4) Water tank (interior): Stainless steel inner tank
5) Manifold : aluminum alloy out casing & red copper flow passage
6) Glass tube: new trivalent element heat tube, borrosilicate glass 3.3
7) Solar working station
8) With heat pipe: anti-freezing > -35 degrees centigrade
9) Water capacity: 150L, 200L, 250L, 300L, 500L
10) Pressure: 6 Bars
11) Daily efficiency: >= 55%(>=42% in winter)
12) Heat preservation: 72h to 80h
13) Electric heater: 1.5Kw to 3Kw
collector
1) Reliable, efficient, twin-glass evacuated tubes
2) Red copper(TU1) heat pipes for rapid heat transferring
3) High efficiency - long term performance
4) Light-weight - easy to transport
5) Attractive design, standard frame suitable for pitched roof or flat roof
6) Reliability and long life
7) Significant advantages over flat plate
8) Easy plug-in installation
9) Suitable for mains pressure water
10) Corrosion resistant
11) Can be connected with the existing heating device
12) Protecting the environment and reducing your fuel cost
13) Domestic and commercial use, solar collector is ideal for both domestic and commercial use, and is scalable to your exact needs. This allows us to be highly competitive.
| Solar collector(Heat pipe series)SC-H series | ||||||||||
| Model | SC-H-15-5818 | SC-H-18-5818 | SC-H-20-5818 | SC-H-24-5818 | SC-H-30-5818 | |||||
| Length of Tube | 1800mm | |||||||||
| Outer Diameter of Tube | φ58mm | |||||||||
| Tube Quantity | 15 | 18 | 20 | 24 | 30 | |||||
| Manifold | casing material,Aluminum Alloy,Thickness,1.8mm,Insulating layer,compressed rock wool | |||||||||
| Heat Pipe | pure red copper TU1+water,transfer power>=150W,Working pressure,4Mpa,welding pressure 4Mpa | |||||||||
| Dust Ring Gasket | Silicon Rubber | |||||||||
| Vacuum Tube | tri-element tube,High boron and silicon content 3.3,Structure,Gradual change SS-AL-Nx/Cu selective absorption coating,Vacuum Degree,P<=5*10-4,Service Life,10 years | |||||||||
| Mounting Frame | Aluminum Alloy,Thickness,1.8 mm, not have back-leg | |||||||||
| Rack Insert | ABS | |||||||||
| Dimension(CBM) | 0.24 | 0.32 | 0.33 | 0.39 | 0.5 | |||||
| Container Loading Quantity(set) | 20 | 102 | 78 | 77 | 63 | 57 | ||||
| 40 | 221 | 169 | 166 | 136 | 130 | |||||
| 40HQ | 278 | 213 | 209 | 172 | 171 | |||||
| Price(USD) | ||||||||||
