Split High Pressuried Solar New Energy Solar Products

Name: Split High Pressuried Solar New Energy Solar Products
Brand: lfpower
SKU: 142958610
Availability: InStock

US$ 100 - 800 MOQ: 3 Sets

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

lfpower

Model Number:

SC-H-5818

Wuyi Lefeng Power Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghia or Ningbo port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name lfpower

Model Number SC-H-5818

Type Pressurized

Application Water Heater

Pipe Material Glass

Specifications

Solar new energy
1.EN12975 solar keymark
2.Anti-freezen & pressurized
3.10 years warranty

Solar new energy

Material of Model:

1.the heater pipe is made of red copper TU1+water,transfer power>150w,working pressure:4MPa,welding pressure:4MPa

2.vacuum tube :tri-element,high boron and silicon content3.3,structure:gradual change SS-AL-Nx/Cu selective absorption coating;life:15 year

3.frame:aluminum alloy,thickness:2.0mm

4.water tank:color steel plate thickness:0.5mm outertank,and inner tank stainless steel 304-2B,thainless 1.5mm,normal working pressure:6 bar

station:circulation pump RS-15/6wilo,controller,expansion tank(italy)

6.the insulating layer uses polyurethane bulk bubble and has a good effect of temperature preservation

Model: tank capacity: 150L,200L,250L,300L,400L,500L,600L,700L,800L............

NOTE:

1.above prices are based on FOB shanghai

2.warranty:5 years for the whole system,10 years for vacuum tubes

3.module design,arbitrary combination,harmonize with the building perfectly

4.intelligent control and automatic operation

at anytime and enjoyable

6.multifunction:bathing,washing,domestic heating,swimming pool, heater floor...

7.anti-freeze:using the anti-freezing liquid as the medium and the controller has anti-freezing function

Solar collector(Heat pipe series)SC-H series
Model		SC-H-15-5818	SC-H-18-5818	SC-H-20-5818	SC-H-24-5818	SC-H-30-5818
Length of Tube		1800mm
Outer Diameter of Tube		φ58mm
Tube Quantity		15	18	20	24	30
Manifold		casing material,Aluminum Alloy,Thickness,1.8mm,Insulating layer,compressed rock wool
Heat Pipe		pure red copper TU1+water,transfer power>=150W,Working pressure,4Mpa,welding pressure 4Mpa
Dust Ring Gasket		Silicon Rubber
Vacuum Tube		tri-element tube,High boron and silicon content 3.3,Structure,Gradual change SS-AL-Nx/Cu selective absorption coating,Vacuum Degree,P<=5*10^-4,Service Life,10 years
Mounting Frame		Aluminum Alloy,Thickness,1.8 mm, not have back-leg
Rack Insert		ABS
Dimension(CBM)		0.24	0.32	0.33	0.39	0.5
Container Loading Quantity(set)	20	102	78	77	63	57
	40	221	169	166	136	130
	40HQ	278	213	209	172	171
Price(USD)
