Help CenterSplit U-type Heat Pipe Solar Collector Product With Tank 300L
Related Products
-
SRCC Split Pressuried Solar Collector System 30 Tubes With 300LUS$ 100 - 800MOQ: 3 Sets -
Split Pressurized Solar Collector System With Two Copper CoilUS$ 100 - 800MOQ: 3 Sets
-
EN12975 Split Pressurized Solar Collector 58*1800mm With 20tubesUS$ 100 - 800MOQ: 3 Sets
-
Homemade Non-pressurized Solar Heater 58*1800 mm TypeNegotiableMOQ: 3 Sets
-
Compact Pressurized Solar Water Heater With Evacuated Tube 58mm*1800mmNegotiableMOQ: 3 Sets
Specifications
Solar collector products1.EN12975 solar keymark
2.Anti-freezen & pressurized
3.10 years warranty
Solar collector products
Material of Model:
1.the heater pipe is made of red copper TU1+water,transfer power>150w,working pressure:4MPa,welding pressure:4MPa
2.vacuum tube :tri-element,high boron and silicon content3.3,structure:gradual change SS-AL-Nx/Cu selective absorption coating;life:15 year
3.frame:aluminum alloy,thickness:2.0mm
4.water tank:color steel plate thickness:0.5mm outertank,and inner tank stainless steel 304-2B,thainless 1.5mm,normal working pressure:6 bar
station:circulation pump RS-15/6wilo,controller,expansion tank(italy)
6.the insulating layer uses polyurethane bulk bubble and has a good effect of temperature preservation
Model: tank capacity: 150L,200L,250L,300L,400L,500L,600L,700L,800L............
solar water collector
1) Reliable, efficient, twin-glass evacuated tubes
2) Red copper(TU1) heat pipes for rapid heat transferring
3) High efficiency - long term performance
4) Light-weight - easy to transport
5) Attractive design, standard frame suitable for pitched roof or flat roof
6) Reliability and long life
7) Significant advantages over flat plate
8) Easy plug-in installation
9) Suitable for mains pressure water
10) Corrosion resistant
11) Can be connected with the existing heating device
12) Protecting the environment and reducing your fuel cost
13) Domestic and commercial use, solar collector is ideal for both domestic and commercial use, and is scalable to your exact needs. This allows us to be highly competitive.
NOTE:
1.above prices are based on FOB shanghai
2.warranty:5 years for the whole system,10 years for vacuum tubes
3.module design,arbitrary combination,harmonize with the building perfectly
4.intelligent control and automatic operation
at anytime and enjoyable
6.multifunction:bathing,washing,domestic heating,swimming pool, heater floor...
7.anti-freeze:using the anti-freezing liquid as the medium and the controller has anti-freezing function
| Solar collector(Heat pipe series)SC-H series | ||||||||||
| Model | SC-H-15-5818 | SC-H-18-5818 | SC-H-20-5818 | SC-H-24-5818 | SC-H-30-5818 | |||||
| Length of Tube | 1800mm | |||||||||
| Outer Diameter of Tube | φ58mm | |||||||||
| Tube Quantity | 15 | 18 | 20 | 24 | 30 | |||||
| Manifold | casing material,Aluminum Alloy,Thickness,1.8mm,Insulating layer,compressed rock wool | |||||||||
| Heat Pipe | pure red copper TU1+water,transfer power>=150W,Working pressure,4Mpa,welding pressure 4Mpa | |||||||||
| Dust Ring Gasket | Silicon Rubber | |||||||||
| Vacuum Tube | tri-element tube,High boron and silicon content 3.3,Structure,Gradual change SS-AL-Nx/Cu selective absorption coating,Vacuum Degree,P<=5*10-4,Service Life,10 years | |||||||||
| Mounting Frame | Aluminum Alloy,Thickness,1.8 mm, not have back-leg | |||||||||
| Rack Insert | ABS | |||||||||
| Dimension(CBM) | 0.24 | 0.32 | 0.33 | 0.39 | 0.5 | |||||
| Container Loading Quantity(set) | 20 | 102 | 78 | 77 | 63 | 57 | ||||
| 40 | 221 | 169 | 166 | 136 | 130 | |||||
| 40HQ | 278 | 213 | 209 | 172 | 171 | |||||
| Price(USD) | ||||||||||
