Help CenterJDP-16 Pedestal 16mm Drill Press
US$ 100 - 200
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Brand Name:
JEMAR
Model Number:
JDP16
Drill Type:
Drill Press
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
JTS-1800 1800W 10" Industrial Sliding Table Saw for WoodworkingUS$ 300 - 500MOQ: 200 Pieces -
12"/305mm Electric Disc SanderUS$ 50 - 100MOQ: 100 Pieces
-
JSC1600VL Woodworking Scroll Saw, Industrial Scroll Saw, Scroll Saw MahineUS$ 50 - 100MOQ: 100 Pieces
-
JCS356 14" ELECTRIC CUT OFF SAW, METAL CUTTING SAWUS$ 50 - 90MOQ: 200 Pieces
-
JBD-516 16mm Bench Drill PressUS$ 30 - 80MOQ: 500 Pieces
Brand Name
JEMAR
Model Number
JDP16
Drill Type
Drill Press
Application
wood, plastic, metal
Frequency
50Hz
Max. Drilling Diameter
16mm
No-Load Speed
215-3,130rpm
Rated Input Power
550W
Rated Voltage
230V
Weight
51.5kg
Specifications
1) 550W2) 16 spindle speeds
3) 16mm drilling capacity
4) Locking depth stop
5) Fully adjustable table with angle indicator
FEATURE:
• Powerful 550W induction motor with cast iron housing for long-lasting, smooth performance
• 16 speeds for optimum drilling performance in a variety of materials
• Adjustable locking depth stop for accurate depth measurement and repetitive drilling
• Built-in light for better visibility of work area
• Pivoting motor mount maintains correct belt tension and facilitates speed change
• Easy reach front positioned on/off switch including safety key
• 16mm drilling capacity for all large drilling applications
• Fully adjustable round table with angle indicator
• Cast iron base for added stability
• 16 speeds for optimum drilling performance in a variety of materials
• Adjustable locking depth stop for accurate depth measurement and repetitive drilling
• Built-in light for better visibility of work area
• Pivoting motor mount maintains correct belt tension and facilitates speed change
• Easy reach front positioned on/off switch including safety key
• 16mm drilling capacity for all large drilling applications
• Fully adjustable round table with angle indicator
• Cast iron base for added stability
SPECIFICATIONS:
| JBD-16 | JDP-16 | |
| Voltage: | 230V 50Hz | 230V 50Hz |
| Power input: | 550W | 550W |
| Max. drilling capacity: | 16mm | 16mm |
| Chuck capacity: | 3-16mm | 3-16mm |
| Spindle taper: | MT2 | MT2 |
| Speeds: | 215-3,130MIN-1 | 215-3,130MIN-1 |
| Swing: | 169mm | 169mm |
| Spindle travel: | 80mm | 80mm |
| Height: | 995mm | 1580mm |
| Distance-spindle to base: | 640mm | 1210mm |
| Max. distance-spindle to table: | 450mm | 775mm |
| Diameter of table: | 290mm | 290mm |
| Net weight: | 46.00kgs | 51.50kgs |
