Hydraulic Breaker, Excavator Breaker, Excavator Hydraulic Breaker
Type: Side Type
Models: ELT53~175
Wholesale Various Hydraulic Breakers (Also called Hydraulic Hammer or Excavator Breaker). They have side type, top type and silenced type, 3 Types in total.
Advantage to Ours:
Reliable Quality;
Lowest Price;
Standard configuration or Selective configuration;
On Time Delivery;
Whole Life Service.
Detailed Features to Side Type Hydraulic Breakers (Also called Hydraulic Hammer, Excavator Breaker, Excavator Hammer, Breaking Hammer etc):
1. Advantages:
High quality material, Advanced facilities and Strict technology;
High quality & Competetive price;
Steady Performance;
Cover all type of excavators;
Accessories is complete;
Reliable afer-sale service;
2. Application Fields:
Mining Industry: Mining, second-time breaking etc;
Metallurgy Industry: Clearing slag, demolition of furnace and foundation etc;
Road & Railway Engineering: Repairing, breaking, foundation work, demolition etc;
Tunneling Engineering: Tunneling work etc;
Construction Engineering: Ground foundation, demolition of bulinding and concrete etc;
Ship Repairing Industry: Clearing clam and rust from the hull;
Other Fields: Breaking frozen mud etc.
3. Specifications to Side Type Series:
| Items/Models | Mini Types | Medium Types | Heavy Types | |||||||||
| ELT53 | ELT68 | ELT75 | ELT85 | ELT100 | ELT125 | ELT135 | ELT140 | ELT150 | ELT155 | ELT165 | ELT175 | |
| Applied Excavator (Tons) |
2.5-4.5 | 4-7 | 6-9 | 7-14 | 11-16 | 15-18 | 18-26 | 19-26 | 25-30 | 28-35 | 30-40 | 40-55 |
| Total Weight (Kgs) |
130 | 250 | 380 | 510 | 765 | 1250 | 1450 | 1770 | 2114 | 2440 | 2600 | 3725 |
| Weight of Main Body (Kgs) |
85 | 151 | 210 | 280 | 471 | 620 | 754 | 911 | 1072 | 1283 | 1443 | 1924 |
| Total Length (MM) |
1140 | 1347 | 1518 | 1737 | 1994 | 2100 | 2200 | 2409 | 2430 | 2731 | 2816 | 3189 |
| Operating Oil Flow (L/Min) |
40-70 | 40-70 | 50-90 | 60-100 | 80-110 | 90~120 | 120-180 | 120-180 | 150-210 | 180-240 | 200-260 | 210-290 |
| Operating Oil Pressure (Bars) |
110-140 | 110-140 | 120-150 | 130-160 | 150-170 | 150-170 | 160-180 | 160-180 | 160-180 | 160-180 | 160-180 | 160-180 |
| Hose Diameter (Inch) |
1/2 | 1/2 | 1/2 | 3/4 | 3/4 | 1 | 1 | 1 | 1 | 1 1/4 | 1 1/4 | 1 1/4 |
| Impact Rate (BPM) |
600-1000 | 500-900 | 400-800 | 400-800 | 350-700 | 350-650 | 350-600 | 350-500 | 300-450 | 300-450 | 250-400 | 200-350 |
| Impact Power (KG.M) |
70 | 70 | 92 | 133 | 214 | 312 | 363 | 429 | 531 | 663 | 918 | 1224 |
| Chisel Diameter (MM) |
53 | 68 | 75 | 85 | 100 | 125 | 135 | 140 | 150 | 155 | 165 | 175 |
4. Applicabale Excavators:
| ELT68 | ELT75 | ELT85 | ELT100 | ELT135 | ELT140 | ELT150 | ELT155 | ELT165 | ELT175 | |
| CASE | 50MAXI | 50 | WX90 9007 |
WX120 588 788 795 900 CX130 |
CX210 1188CK 9021N |
CX210 1188CK 9021N |
1288LC | 1288LC | 1488LC 9033 |
CX360B CX460 |
| CAT | CT60 | CT60 | 307 311 |
CT205 CT207 |
CT320 CT322 CT325 |
CT320 CT322 CT325 |
CT325 CT330 |
335 330L E300 225 |
E300 225 |
345BL |
| CHANGJIANG | WY60 | WY120 WY203 |
WY203 |
WY160 WY252 |
WY160 WY252 WY403 |
WY402 WT452 |
||||
| DOOSAN DAEWOO |
DH35 DH55 DH60 |
DH35 DH55 DH60 |
DH80 | DH130 DH150 |
DH210W DH125 DH220 DH225 DH258 |
DH210W DH125 DH220 DH225 DH258 |
DH300 DH330 DH360 DH370 |
DH300 DH330 DH360 DH370 DH420 |
DH360 DH370 DH420 |
DH420 DH500 |
| FOTONLOVOL | FR39 FR60 |
FR60 | FR80 | FR130 | FR200 FR230 |
FR200 FR230 |
||||
| HITACHI | ZX35 ZX55 ZX60 ZX70 |
ZX55 ZX60 ZX70 ZX75 |
ZX90 ZX100 |
ZX100 ZX120 ZX135 ZX150 |
ZX200 ZX210 ZX220 |
ZX210 ZX220 ZX230 ZX250 |
ZX270 ZX280 ZX330 |
ZX300 ZX350 ZX360 |
ZX350 ZX360 ZX400 |
ZX400 ZX450 |
| HYUNDAI | R55 R60 |
R55 R60 |
R80 | R110 R130 |
R200 R210 R215 R220 R225 |
R200 R210 R215 R220 R225 |
R290 R300 R305 R335 R360 |
R305 R335 R360 R420 |
R360 R420 |
R385 R420 R450 |
| JOHN DEER | 50 | 50 | 70D | JD34 | JD55 790D |
JD55 790D |
890 | 890 | 892 | |
| JONYANG | JY35 | JYL80 | JYL80 | JYL161 | JYL210E JY200E JY230 |
JYL210E JY230E |
JY320 | JY320 | ||
| KATO | HD180 HD250 |
HD250 HD400 |
HD399 HD400 |
HD450 HD500 |
HD700 HD800 HD820 |
HD820 HD880 HD1023 |
HD1100 HD1200 HD1250 |
HD1200 HD1250 HD1430-3 HD1500 |
HD1500 HD1800 HD2500 |
HD1880 |
| KOBELCO | SK35 SK55 SK70 |
SK35 SK55 SK70 |
SK70 | KS115 SK135 |
SK115 SK135 SK200 SK220 |
SK220 SK230 SK250 |
SK300 SK320 SK330 SK350 |
SK320 SK330 SK350 SK400 |
SK400 SK450 |
SK450 |
| KOMATSU | PC50 PC60 |
PC50 PC60 |
PC80 | PC100 PC120 PC130 |
PC200 PC210 PC220 |
PC200 PC210 PC220 |
PC250 PC300 |
PC250 PC300 |
PC300 PC350 |
PC400 PC450 |
| LIEBHEER | A310 | A310 | A310 | R310 R312 A901 |
A912 A922 R912 |
A912 A922 R912 |
R922LIT R932LIT 934 |
944 R922 R932LIT |
R944B |
R952 R954LIT |
| LIUGONG | CLG905 | CLG907 | CLG908 | CLG200 CLG920 |
CLG210 CLG230 CLG920 CLG923C CLG925 |
|||||
| LISHIDE | SC60.7 | SC130.7 | SC130.7 | SC200.8 SC210.7 |
SC210.7 SC220.7 SC230.8 |
SC330.7 | SC360.7 |
|||
| SANY | SY60 SY65 |
SY60 SY65 |
SY75 | SY135 | SY200 SY210 SY220 SY230 |
SY200 SY210 SY220 SY230 |
SY330 SY360 |
SY330 SY360 |
SY420 | SY425C SY465C |
| SUMITOMO | S140 S160 |
S140 S160 |
S35 S250 |
S40 S260 S265 |
S200 S260 S280 |
S200 S260 S280 |
S300 S90 S340 |
S100 S340 S390 |
S390 S430 |
SH380T SH460 |
| VOLVO | EC45 EC55 EC60 |
EC45 EC55 EC60 |
EC140 | EC210 EC240 |
EC210 EC240 |
EC290 | EC290 EC360 |
EC360 | EC360 EC460 |
|
| YUCAI | YC55 | YC65 | YC85 | YC135 | YC210 | YC210 YC230 YC240 YC260 |
YC330 YC360 |
YC330 YC360 |
||
| JCB | 8056 | JS130 | JS130 JS145 |
JS160 JS175 |
JS175 JS200 JS220 JS240 |
JS240 | JS290 | JS290 JS360 |
JS360 JS460 |
|
| LOADER | ZL10 ZL30 ZL35 |
ZL10 ZL30 ZL40 |
ZL40 ZL50 |
ZL50 |
