Home > Industrial Equipment & Components > Bearing > Pillow Block Bearing > UCFL206 Pillow Block

UCFL206 Pillow Block

UCFL206 Pillow Block thumbnail-1
UCFL206 Pillow Block photo-1
US$ 2 - 8 MOQ: 200 Pieces
Key Specifications
Get Latest Price
Bore Size:
1, 3
Brand Name:
Neutral
Model Number:
UCFL206
Contact Supplier Request Quote Chat Now
Shaanxi Topmi Arts & Crafts Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Bore Size 1, 3
Brand Name Neutral
Model Number UCFL206

pillow block:



UCFL200 series pillow block bearings:



UCFL206 pillow block







Code NO. Shaft Dia  Boundary dimensions (mm) Specifications Bearing NO. Housing NO. Weight (kg)
d H L L A2 A1 A E N S A4
(in.) (mm)
 UCFL201 2   224 184 130 25 18 48 58.4 18 22.2 64 M16 UC211-32 FL211 3.1
 UCFL201-8 2 1/8   224 184 130 25 18 48 58.4 18 22.2 64 M60 UC211-34 FL211 3.1
 UCFL201-8S 2 1/8   224 184 130 25 18 48 58.4 18 22.2 64 M16 UC211-34 FL211 3.1
 UCFL201S   55 224 184 130 25 18 48 58.4 18 22.3 64 M16 UC211 FL211 3.1
 UCFL202 2  3/16   224 184 130 25 18 48 58.4 18 22.2 64 M16 UC211-35 FL211 3.1
 UCFL202-10 2 1/4   250 202 140 29 18 48 68.7 18 25.4 74.5 M16 UC212-36 FL212 4
 UCFL202-10S   12 99 76.5 57 15 11 25 30.9 11.5 11.5   M10 UC201S FL203 0.45
 UCFL202S 1/2      99 76.5 57 15 11 25 30.9 11.5 11.5   M10 UC201-8S FL203 0.45
 UCFL203   15 99 76.5 57 15 11 25 30.9 11.5 11.5   M10 UC202S FL203 0.45
 UCFL203-11 5/8      99 76.5 57 15 11 25 30.9 11.5 11.5   M10 U202-10S FL203 0.45
 UCFL203-11S   17 99 76.5 57 15 11 25 30.9 11.5 11.5   M10 UC203S FL203 0.45
 UCFL203C  11/16   99 76.5 57 15 11 25 30.9 11.5 11.5   M10 UC203-11S FL203 0.45
 UCFL204   12 113 90 60 15 11 26 33.3 11.5 12.7 37.5 M10 UC201 FL204 0.51
 UCFL204-12 1/2      113 90 60 15 11 26 33.3 11.5 12.7 37.5 M10 UC201-8 FL204 0.51
 UCFL205   15 113 90 60 15 11 26 33.3 11.5 12.7 37.5 M10 UC202 FL204 0.51
 UCFL205-14 5/8     113 90 60 15 11 26 33.3 11.5 12.7 37.5 M10 UC202-10 FL204 0.51
 UCFL205-15   17 113 90 60 15 11 26 33.3 11.5 12.7 37.5 M10 UC203 FL204 0.51
 UCFL205-16  11/16   113 90 60 15 11 26 33.3 11.5 12.7 37.5 M10 UC203-11 FL204 0.51
 UCFL206 3/4     113 90 60 15 11 26 33.3 11.5 12.7 37.5 M10 UC204-12 FL204 0.51
 UCFL206-18   20 113 90 60 15 11 26 33.3 11.5 12.7 37.5 M10 UC204 FL204 0.51
 UCFL206-19 7/8     130 99 68 16 13 27 35.7 11.5 14.3 40 M10 UC205-14 FL205 0.6
 UCFL206-20 15/16   130 99 68 16 13 27 35.7 11.5 14.3 40 M10 UC205-15 FL205 0.6
 UCFL207   25 130 99 68 16 13 27 35.7 11.5 14.3 40 M10 UC205 FL205 0.6
 UCFL207-20 1   130 99 68 16 13 27 35.7 11.5 14.3 40 M10 UC205-16 FL205 0.6
 UCFL207-21 1 1/8   148 117 80 18 13 31 40.2 11.5 15.9 44 M10 UC206-18 FL206 0.9
 UCFL207-22   30 148 117 80 18 13 31 40.2 11.5 15.9 44 M10 UC206 FL206 0.9
 UCFL207-23 1  3/16   148 117 80 18 13 31 40.2 11.5 15.9 44 M10 UC206-19 FL206 0.9
 UCFL208 1 1/4   148 117 80 18 13 31 40.2 11.5 15.9 44 M10 UC206-20 FL206 0.9
 UCFL208-24 1 1/4   161 130 90 19 14 34 44.4 14 17.5 48.5 M12 UC207-20 FL207 1.2
 UCFL208-25 1  5/16   161 130 90 19 14 34 44.4 14 17.5 48.5 M12 UC207-21 FL207 1.2
 UCFL209 1 3/8   161 130 90 19 14 34 44.4 14 17.5 48.5 M12 UC207-22 FL207 1.2
 UCFL209-26   35 161 130 90 19 14 34 44.4 14 17.5 48.5 M12 UC207 FL207 1.2
 UCFL209-27 1  7/16   161 130 90 19 14 34 44.4 14 17.5 48.5 M12 UC207-23 FL207 1.2
 UCFL209-28 1 1/2   175 144 100 21 14 36 51.2 14 19 55 M12 UC208-24 FL208 1.5
 UCFL210 1  9/16   175 144 100 21 14 36 51.2 14 19 55 M12 UC208-25 FL208 1.5
 UCFL210   40 175 144 100 21 14 36 51.2 14 19 55 M12 UC08 FL208 1.5
 UCFL210-30 1 5/8   188 148 108 22 16 38 52.2 18 19 57 M16 UC209-26 FL209 1.9
 UCFL210-31 1 11/16   188 148 108 22 16 38 52.2 18 19 57 M16 U209-27 FL209 1.9
 UCFL210-32 1 3/4   188 148 108 22 16 38 52.2 18 19 57 M16 UC209-28 FL209 1.9
 UCFL211   45 188 148 108 22 16 38 52.2 18 19 57 M16 UC209 FL209 1.9
 UCFL211-32 1 7/8   197 157 115 22 16 40 54.6 18 19 60 M16 UC210-30 FL210 2.2
 UCFL211-34 1 15/16   197 157 115 22 16 40 54.6 18 19 60 M16 UC210-31 FL210 2.2
 UCFL211-34   50 197 157 115 22 16 40 54.6 18 19 60 M16 UC210 FL210 2.2
 UCFL211-35   50 197 157 115 22 16 40 54.6 18 19 60 M16 UC210 FL210 2.2
 UCFL212 2   197 157 115 22 16 40 54.6 18 19 60 M16 UC210-32 FL210 2.2
